Manufacturer Part#: WIC-4ESW
WIC-4ESW Cisco WAN Interface card
WIC-4ESW 4 x 10/100Base-TX - WAN Interface Card (WIC)
WIC-4ESW
Cisco WIC-4ESW General Information:
Brand Name: Cisco
Product Series: 1700
Product Name: WAN Interface Card (WIC)
Product Type: WAN Interface Card (WIC)
Cisco WIC-4ESW Interfaces/Ports:
Interfaces/Ports: 4 x 10/100Base-TX WAN
Interfaces/Ports Details: 4 x RJ-45 10/100Base-TX WAN
Cisco WIC-4ESW Media & Performance:
Data Transfer Rate: 100Mbps Fast Ethernet Half/Full-duplex
Data Transfer Rate: 200Mbps Fast Ethernet Full-duplex
Data Transfer Rate: 10Mbps Ethernet Half/Full-duplex
Cisco WIC-4ESW Controls/Indicators:
Status Indicators:
•Link
•Activity
Cisco WIC-4ESW Environmental Conditions:
Temperature: 0 degrees C (32.0 degrees F) to 40 degrees C (104.0 degrees F) Operating
Temperature: -20 degrees C (-4.0 degrees F) to 65 degrees C (149.0 degrees F) Non-operating
Humidity: 10% to 85% Non-condensing Relative Humidity Operating
Humidity: 5% to 95% Non-condensing Relative Humidity Non-operating
Cisco WIC-4ESW Physical Characteristics:
Dimensions: 0.8 Height x 3.1 Width x 4.8 Depth
Shipping Dimensions: 2 Height x 9.25 Width x 12.19 Depth
Weight: 1.92 oz
Shipping Weight: 1.1 lb
Cisco WIC-4ESW Miscellaneous:
Additional Information:
•Modular Router Solutions:
ATM Edge Connectivity
Advanced Network Services
DCN (Data Communications Network)
Ethernet Switching
TDM/Drop&Insert
ATM Edge Connectivity
Advanced Network Services
DCN (Data Communications Network)
Ethernet Switching
TDM/Drop&Insert
•16 IEEE 802.1Q VLANs:
Enables support and management of LAN and WAN configurations on a single device
Provides flexibility to deploy DMZ configuration, wireless access segment, and separate voice and data segments for IP telephony deployment
Allows for increased LAN segmentation
Increases network performance by controlling broadcast traffic
Enables inter-VLAN routing
4 VLANs per switched port
•Spanning Tree Protocol and IEEE 802.1D:
Enhances network reliability
Provides path redundancy while preventing undesirable loops in the network
•IEEE 802.1p traffic prioritization:
Allows traffic prioritization, giving the highest priority to packets containing time-sensitive data, such as interactive voice and video traffic
•Half- and full-duplex support on each port:
Provides further control of performance and bandwidth utilization, allowing data to simultaneously flow to and from the router
