CISCO1760-V-CCME

Manufacturer Part#: Cisco CISCO1760-V-CCME
CISCO1760-V-CCME 1700 Series Modular Access Routers

CISCO1760-V-CCME - Router - 1 x 10/100Base-TX LAN

Cisco 1760 router offers customers secure Internet and intranet access, as well as the capability to implement a variety of e-business and voice applications. This includes voice over IP (VoIP), virtual private network (VPN) access, and business-class digital subscriber line (DSL) as required.

Cisco CISCO1760-V-CCME General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: 1700
Product Name: 1760 Router
Product Type: Router

Cisco CISCO1760-V-CCME Interfaces/Ports:
Number of Ports: 1
Fast Ethernet Port: Yes
Interfaces/Ports: 1 x RJ-45 10/100Base-TX 10/100Base-TX LAN
Interfaces/Ports: 1 x RJ-45 Auxiliary Management
Interfaces/Ports: 1 x RJ-45 Console Management

Cisco CISCO1760-V-CCME Media & Performance:
Connectivity Media: Category 3 10Base-T
Connectivity Media: Category 4 10Base-T
Connectivity Media: Category 5 10/100Base-TX
Distance Support: 328 ft

Cisco CISCO1760-V-CCME I/O Expansions:
Number of Expansion Slots: 5
Expansion Slots: (1 Total) Expansion Slot
Expansion Slots: (2 Total) VIC/WIC
Expansion Slots: (2 Total) VIC
Modules: 1 x PVDM-256K-4 DSP

Cisco CISCO1760-V-CCME Management & Protocols:
Management:
Supports Cisco Configmaker v.2.6
Manageable via SNMP
Supports CiscoView and Telnet, and provides console port
Provides SETUP configuration utility, AutoInstall, command-line interface, context-sensitive configuration questions
Supports Cisco Configmaker v.2.6
Manageable via SNMP
Supports CiscoView and Telnet, and provides console port
Provides SETUP configuration utility, AutoInstall, command-line interface, context-sensitive configuration questions

Cisco CISCO1760-V-CCME Memory:
Standard Memory: 128MB
Maximum Memory: 128MB
Memory Technology: DRAM
Flash Memory: 32 MB

Cisco CISCO1760-V-CCME Controls/Indicators:
Controls: Power Switch
Status Indicators:
System LEDs

Cisco CISCO1760-V-CCME Software:
Operating System:
Cisco 1700 IOS IP/ADSL/VOX PLUS
Cisco 1700 IOS IP/ADSL/VOX PLUS

Cisco CISCO1760-V-CCME Power Description:
Input Voltage: 110V AC
Input Voltage: 220V AC
Input Voltage Range: 100V AC to 240V AC
Input Current: 1.5A
Frequency: 50 Hz or 60 Hz
Power Consumption: 50W Maximum
Power Source: Power Supply

Cisco CISCO1760-V-CCME Environmental Conditions:
Temperature: -4 degrees F (-20.0 degrees C) to 149 degrees F (65.0 degrees C) Storage
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Humidity: 5% to 95% Non-condensing Relative Humidity Storage
Humidity: 10% to 85% Non-condensing Relative Humidity Operating

Cisco CISCO1760-V-CCME Physical Characteristics:
Form Factor: Rack-mountable
Dimensions: 1.7 Height x 17.5 Width x 12.8 Depth
Shipping Dimensions: 7 Height x 16.75 Width x 22 Depth
Weight: 8.2 lb
Weight: 9.4 lb
Shipping Weight: 15.5 lb

Cisco CISCO1760-V-CCME Original Manufacturer Warranty:
Standard Warranty: 1 Year Limited
