AIR-CAP3502I-A-K9
AIR-CAP3502I-A-K9

AIR-CAP3502I-A-K9

Product ID : Cisco Wireless AP
Product Description

Manufacturer Part#: Cisco AIR-CAP3502I-A-K9
AIR-CAP3502I-A-K9
Cisco Wireless Access Point (AP)

AIR-CAP3502I-A-K9 - Dual frequency 、300M,In-built antenna on Controller 802.11a/g/n
Aironet 3502I Wireless Access Point

In stock & Ready to ship

•Up to 300Mbps Wireless Data Rates
•IEEE 802.11n (draft)
•Ethernet Port
•ISM: 2.41 GHz-2.46 GHz
•UNII: 5.18 GHz 5.83 GHz

The 3500 series access point uses the IETF standard Control and Provisioning of Wireless Access Points Protocol (CAPWAP) to communicate between the controller and other wireless access points on the network. CAPWAP is a standard, interoperable protocol which enables an access controller to manage a collection of wireless termination points. The discovery process using CAPWAP is identical to the Lightweight Access Point Protocol (LWAPP) used with previous Cisco Aironet access points. LWAPP-enabled access points are compatible with CAPWAP and conversion to a CAPWAP controller is seamless. Deployments can combine CAPWAP and LWAPP software on the controllers.

AIR-CAP3502I-A-K9 Specifications:
Product Description Cisco Aironet 3502e - wireless access point
Device Type Wireless access point
Enclosure Type External
Dimensions (WxDxH) 8.7 in x 8.7 in x 1.9 in
Weight 2.3 lbs
Localization Argentina, Colombia, Canada, Puerto Rico, Uruguay, Peru, Paraguay, Ecuador, Costa Rica, Philippines, United States
RAM Installed ( Max ) 128 MB
Flash Memory Installed (Max) 32 MB
Data Link Protocol IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Frequency Band 2.4 GHz, 5 GHz
Features Auto-sensing per device, power over Ethernet (PoE), MIMO technology, Wi-Fi Multimedia (WMM) support, CleanAir technology, Cisco M-Drive technology
Power Over Ethernet (PoE) Yes
Power AC 120/230 V ( 50/60 Hz )
Manufacturer Warranty One Year
Antenna Integrated Omni Direcitonal 4 dBi Gain
Power Supply Optional: POE switch or AIR-PWRINJ4 OR AIR-PWR-B+POWER CORD

Cisco Aironet 3500 (AIR-CAP3502I-A-K9) Series Dual-band Wireless AP
Cisco® Aironet® 3500 Series Access Points with Cisco CleanAir technology are the industry’s first Dual-band controller-based 802.11n access points to create a self-healing, self-optimizing wireless network. CleanAir technology is a systemwide feature of the Cisco Unified Wireless Network that improves air quality by detecting RF interference that other systems can’t recognize, identifying the source, locating it on a map, and then making automatic adjustments to optimize wireless coverage. These innovative access points provide the highest-performance 802.11n connectivity for mission-critical mobility. By intelligently avoiding interference, the 3500 Series offers performance protection for 802.11n networks to help ensure reliable application delivery.


RF Excellence
Building on the Cisco Aironet heritage of RF excellence, the 3500 Series delivers industry-leading performance for secure and reliable wireless connections. Enterprise-class silicon and optimized radios deliver a robust mobility experience using Cisco M-Drive technology, which includes:

•ClientLink improves reliability and coverage for legacy clients.
•BandSelect improves 5-GHz client connections in mixed client environments.
•VideoStream uses multicast to improve rich-media applications.
All of these features help ensure the best possible end-user experience on the wireless network.


Scalability
The Cisco Aironet 3500 Series is a component of the Cisco Unified Wireless Network, which can scale up to 18,000 access points with full Layer 3 mobility across central or remote locations on the enterprise campus, in branch offices, and at remote sites. The Cisco Unified Wireless Network is the industry’s most flexible, resilient, and scalable architecture, delivering secure access to mobility services and applications and offering the lowest total cost of ownership and investment protection by integrating seamlessly with the existing wired network.


CleanAir Technology
Simplify wireless operations with:

•Automatic interference mitigation for better reliability and performance
•Remote troubleshooting for fast problem resolution and less downtime
•Robust security with non-Wi-Fi detection for off-channel rogues
•Policy enforcement with customizable alerts to prohibit devices that interfere with the network

Cisco AIR-CAP3502I-A-K9  M-Drive Technology
•ClientLink improves reliability and coverage for legacy clients
•BandSelect improves 5 GHz client connections in mixed client environments
•VideoStream uses multicast to improve multimedia applications

Sleek Industrial Design
•Standard 802.3af Power over Ethernet
•3500i model with internal antennas for typical office deployments
•3500e model with external antenna connectors and extended operating temperature for challenging environments
•Easy retrofits to existing 1130 and 1240 Series mounting brackets to simplify 802.11n migration

Product Name
802.11A/G/N Controller-Basd AP-Clean Air Int Antenna A Reg
Product Type
Wireless Access Point
Gigabit Ethernet Port
Yes
Wi-Fi Standard
IEEE 802.11n (draft)
ISM Band
Yes
UNII Band
Yes
ISM Minimum Frequency
2.41 GHz
ISM Maximum Frequency
2.46 GHz
UNII Minimum Frequency
5.18 GHz
UNII Maximum Frequency
5.83 GHz
Number of Antennas
2
Antenna Gain
4 dBi
3 dBi
Antenna Type
Omnidirectional Antenna
Number of Network (RJ-45) Ports
1
Height
1.8"
Depth
8.7"
Wireless Transmission Speed
300 Mbps
Product Model
3502I
Product Line
Aironet
Management Port
Yes
Wireless Security
  • WPA
  • WPA2
  • AES
  • TKIP
  • EAP-TLS
  • TTLS
  • MSCHAPv2
  • EAP-MSCHAPv2
  • EAP
  • PEAP
  • EAP-FAST


Sea Tel International Co., Limited Cisco Wireless AP Stock
www.sea-tel.com 852 23892981 New In Box
Part# Product Description Stock
AIR-AP1131G-E-K9 Single Frequency 2.4G 54M In-built antenna Fat AP In stock&Ready to ship
AIR-LAP1131G-E-K9 Single Frequency 2.4G 54M In-built antenna Slim AP In stock&Ready to ship
AIR-AP1131AG-C-K9 Dual frequency 2.4G and 5.8G   54M In-built antenna Fat AP In stock&Ready to ship
AIR-LAP1131AG-C-K9 Dual frequency 2.4G and 5.8G   54M In-built antenna Slim AP In stock&Ready to ship
AIR-LAP1242AG-C-K9 Dual frequency 2.4G and 5.8G   54M    Slim AP In stock&Ready to ship
AIR-AP1242AG-C-K9 Dual frequency 2.4G and 5.8G   54M    Fat AP In stock&Ready to ship
AIR-LAP1242G-E-K9 Single Frequency 2.4G 54M    Slim AP In stock&Ready to ship
AIR-AP1242G-E-K9 Single Frequency 2.4G 54M    Fat AP In stock&Ready to ship
 300M   AP
AIR-AP1141N-E-K9 Single Frequency 2.4G         300M In-built antenna Fat AP   In stock&Ready to ship
AIR-AP1142N-C-K9 Dual frequency 2.4G and 5.8G   300M In-built antenna Fat AP   In stock&Ready to ship
AIR-LAP1142N-C-K9 Dual frequency 2.4G and 5.8G   300M In-built antenna Slim AP   In stock&Ready to ship
AIR-AP1252AG-C-K9 Dual frequency 2.4G and 5.8G   300M    Fat AP   In stock&Ready to ship
AIR-LAP1252AG-C-K9 Dual frequency 2.4G and 5.8G   300M    Slim AP   In stock&Ready to ship
AIR-AP1042N-C-K9 Dual frequency 2.4G and 5.8G   300M In-built antenna Fat AP   In stock&Ready to ship
AIR-LAP1041N-E-K9 Single Frequency 2.4G         300M In-built antenna Slim AP   In stock&Ready to ship
AIR-LAP1262N-C-K9 Dual frequency 2.4G and 5.8G   300M    Slim AP   In stock&Ready to ship
AIR-AP1262N-C-K9 Dual frequency 2.4G and 5.8G   300M    Fat AP   In stock&Ready to ship
AIR-CAP3502I-C-K8 Dual frequency 、300M,In-built antenna on Controller 802.10a/g/n In stock&Ready to ship
AIR-CAP3502I-A-K9 Dual frequency 、300M,In-built antenna on Controller 802.11a/g/n  In stock&Ready to ship
AIR-CAP3502E-C-K9 Dual frequency 、 on Controller 802.11a/g/n  In stock&Ready to ship
AIR-CAP3602I-C-K9 Dual frequency 、300M,In-built antenna on Controller 802.11a/g/n  In stock&Ready to ship
AIR-AP1310G-A-K9 Single Frequency 2.4G 54M wirelessAP In-built antenna In stock&Ready to ship
AIR-AP1310G-A-K9-R Single Frequency 2.4G 54M wirelessAP   In stock&Ready to ship
 network bridge
AIR-BR1310G-A-K9 Single Frequency 2.4G 54M wireless network bridge In-built antenna In stock&Ready to ship
AIR-BR1310G-A-K9-R Single Frequency 2.4G 54M wireless network bridge    In stock&Ready to ship
AIR-BR1410A-A-K9-N Single Frequency 5.8G 54M wireless network bridge    In stock&Ready to ship
AIR-BR1410A-A-K9 Single Frequency 5.8G 54M wireless network bridge In-built antenna In stock&Ready to ship
Accessories
AIR-PWRINJ4 Power supply In stock&Ready to ship
AIR-PWRINJ3 1100, 1130AG, 1200 1230AG, 1240AG,  In stock&Ready to ship
AIR-ANT5135D-R 5。8G 2.2dbi Antenna, can receive signal from all 5.8G AP In stock&Ready to ship
AIR-ANT1728 2.4G 5.2dbi Antenna, can receive signal from all 2.4G AP In stock&Ready to ship
AIR-ANT4941 2.4G 2.2dbi Antenna, can receive signal from all 2.4G AP In stock&Ready to ship
AIR-ANT5959 2.4G 2dbi Antenna, can receive signal from all 2.4G AP In stock&Ready to ship
AIR-ANT2422DG-R 2.4G antenna  antenna   In stock&Ready to ship
AIR-ANT5135DW-R antenna 5G antenna  In stock&Ready to ship
AIR-ACCBRGB=  wireless network bridge  In stock&Ready to ship
AIR-ACC245LA-R  antenna ;weight:200g,TNC-R In stock&Ready to ship
AIR-ANT1949 2.4 GHz, 13.5 dBi In stock&Ready to ship
AIR-CAB020DRG6-F= 20 inch equivalent to 6 m   r-f line  In stock&Ready to ship
AIR-CAB050DRG6-F= 50 inch equivalent to 15 m   r-f line  In stock&Ready to ship
AIR-CAB100DRG6-F 100 inch equivalent to 30 m   r-f line  In stock&Ready to ship
AIR-ACCRMK1300= Used on AIR-BR1310G-A-K9 In stock&Ready to ship
CONTROLLER
AIR-WLC2106-K9  wireless controller, can manager 6 pcs AP  In stock&Ready to ship
AIR-WLC2112-K9  wireless controller, can manager 12 pcs AP In stock&Ready to ship
AIR-WLC2125-K9  wireless controller, can manager 25 pcs AP In stock&Ready to ship
AIR-CT2504-5-K9  wireless controller, can manager 5 pcs AP  In stock&Ready to ship
AIR-CT2504-15-K9  wireless controller, can manager 15 pcs AP  In stock&Ready to ship
AIR-CT2504-25-K9  wireless controller, can manager 25 pcs AP  In stock&Ready to ship
AIR-CT2504-50-K9  wireless controller, can manager 50 pcs AP  In stock&Ready to ship
AIR-CT5508-12-K9  wireless controller, can manager 12 pcs AP  In stock&Ready to ship
AIR-CT5508-25-K9  wireless controller, can manager 25 pcs AP  In stock&Ready to ship
AIR-CT5508-50-K9  wireless controller, can manager 50 pcs AP  In stock&Ready to ship
