AIR-CAP2602I-E-K9

Manufacturer Part# :  Cisco AIR-CAP2602I-E-K9
Cisco AIR-CAP2602I-E-K9 Aironet 2602i Controller Based Radio Access Point
802,11n CAP w/CleanAir; 3x4:3SS; Mod; Int Ant; E Reg Domain

AIR-CAP2602I-E-K9 Cisco Aironet 2602i Controller Based Dual-Band Wireless-N Access Point w/ Internal Antennas (450Mbps)

Cisco Aironet 2600 series Access Point delivers the most advanced features in its class - with great performance, functionality, and reliability at a great price. The 802.11n based Aironet 2600 series includes 3x4 MIMO, with three spatial streams, plus Cisco CleanAir, ClientLink 2.0, and VideoStream technologies, to help ensure an interference-free, high-speed wireless application experience. Second only to the Cisco Aironet 3600 Series in performance and features, the Aironet 2600 Series sets the new standard for enterprise wireless technology.

Designed with rapidly evolving mobility needs in mind, the Aironet 2600 series access point is packed with more Bring Your Own Device (BYOD)-enhancing functionality than any other access point at its price point. The Cisco Aironet 2600 series sustains reliable connections at higher speeds farther from the access point than competing solutions resulting in more availability of 450 Mbps data rates. Optimized for consumer devices, the Aironet 2600 series accelerates client connections and consumes less mobile device battery power than competing solutions.

AIR-CAP2602I-E-K9 Main features:
•Based on 802.11n with 3x4 MIMO technology with three spatial streams to sustain 450 Mbps rates over a greater range for more capacity and reliability than competing access points
•Cisco ClientLink 2.0 technology for better downlink performance and range for all mobile devices and better battery life on mobile devices such as smartphones and tablets
•Cisco CleanAir technology for proactive,intelligent spectrum intelligence to combat performance problems due to RF interference

AIR-CAP2602I-E-K9 Technical Details
Brand Cisco
Item Weight 907 g
Product Dimensions 22.9 x 5.1 x 22.9 cm
Item model number AIR-CAP2602I-E-K9
RAM Size 256 MB

AIR-CAP2602I-E-K9 Software
•Cisco Unified Wireless Network Software Release 7.2.110 or later.

AIR-CAP2602I-E-K9 802.11n Version 2.0 (and Related) Capabilities
•3x4 multiple-input multiple-output (MIMO) with three spatial streams
•Maximal ratio combining (MRC)
•802.11n and 802.11a/g beamforming
•20- and 40-MHz channels
•PHY data rates up to 450 Mbps (40-MHz with 5 GHz)
•Packet aggregation: Aggregated MAC Protocol Data Unit (A-MPDU) (Tx/Rx), Aggregated MAC Protocol Service unit (A-MSDU) (Tx/Rx)
•802.11 dynamic frequency selection (DFS)
•Cyclic shift diversity (CSD) support

AIR-CAP2602I-E-K9 Integrated Antenna
•2.4 GHz, Gain 4 dBi, internal omnidirectional, horizontal beamwidth 360°
•5 GHz, Gain 4 dBi, internal omnidirectional, horizontal beamwidth 360°

AIR-CAP2602I-E-K9 External Antenna (Sold Separately)
•Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)

AIR-CAP2602I-E-K9 Interfaces
•10/100/1000BASE-T autosensing (RJ-45)
•Management console port (RJ-45)

AIR-CAP2602I-E-K9 Indicators
•Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors

AIR-CAP2602I-E-K9 Dimensions
•(W x L x H)
◦Access point (without mounting bracket): 8.69x8.69x2.11in. (22.1x22.1x5.4)

AIR-CAP2602I-E-K9 Weight
•2.3 lbs (1.04 kg) (2.7 lbs for external)

AIR-CAP2602I-E-K9 Environmental
•Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C)
•Nonoperating (storage) Altitude Test 25°C, 15,000 ft.
•Operating temperature: 32 to 104°F (0 to 40°C)
•Operating humidity: 10 to 90% percent (noncondensing)
•Operating Altitude Test: 40°C, 9843 ft.

AIR-CAP2602I-E-K9 System Memory
•256 MB DRAM
•32 MB flash

AIR-CAP2602I-E-K9 Input Power Requirements
•44 to 57 VDC

AIR-CAP2602I-E-K9 Power Supply and Power Injector
•100 to 240 VAC; 50 to 60 Hz

AIR-CAP2602I-E-K9 Powering Options
•802.3af Ethernet Switch
•Cisco AP2600 Power Injectors (AIR-PWRINJ4=)
•Cisco AP2600 Local Power Supply (AIR-PWR-B=)

AIR-CAP2602I-E-K9 Power Draw
•12.95W

AIR-CAP2602I-E-K9 Warranty
•Limited Lifetime Hardware Warranty

AIR-CAP2602I-E-K9 Compliance Standards
•UL 60950-1
•CAN/CSA-C22.2 No. 60950-1
◦UL 2043
◦IEC 60950-1
◦EN 60950-1
◦EN 50155
•Radio approvals:
◦FCC Part 15.247, 15.407
◦EN 300.328, EN 301.893 (Europe)
◦EMI and susceptibility (Class B)
◦FCC Part 15.107 and 15.109
◦EN 301.489-1 and -17 (Europe)
◦EN 60601-1-2 EMC requirements for the Medical Directive 93/42/EEC
•IEEE Standard:
◦IEEE 802.11a/b/g, IEEE 802.11n, IEEE 802.11h, IEEE 802.11d
•Security:
◦802.11i, Wi-Fi Protected Access 2 (WPA2), WPA 802.1X
◦Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)
•EAP Type(s):
◦Extensible Authentication Protocol-Transport Layer Security (EAP-TLS)
◾EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
◦Protected EAP (PEAP) v0 or EAP-MSCHAPv2
◦Extensible Authentication Protocol-Flexible Authentication via Secure Tunneling (EAP-FAST)
◦PEAPv1 or EAP-Generic Token Card (GTC)
◦EAP-Subscriber Identity Module (SIM)

AIR-CAP2602I-E-K9 Multimedia:
◦Wi-Fi Multimedia (WMM™)
•Other:
◦FCC Bulletin OET-65C
◦RSS-102

AIR-CAP2602I-E-K9 Marketing Information
The new Cisco® Aironet® 2600 Series Access Point delivers the most advanced features in its class - with great performance, functionality, and reliability at a great price. The 802.11n based Aironet 2600 Series includes 3x4 MIMO, with three spatial streams, plus Cisco CleanAir™, ClientLink 2.0™, and VideoStream technologies, to help ensure an interference-free, high-speed wireless application experience. Second only to the Cisco Aironet 3600 Series in performance and features, the Aironet 2600 Series sets the new standard for enterprise wireless technology.

AIR-CAP2602I-E-K9 General Information
Manufacturer: Cisco
Product ID: AIR-CAP2602I-E-K9
Product Description: 802.11n CAP w/CleanAir; 3x4:3SS; Mod; Int Ant; E Reg Domain
Product Type: Wireless Access Point

AIR-CAP2602I-E-K9 Technical Information
Wi-Fi Standard: IEEE 802.11n
ISM Band: Yes
UNII Band: Yes
ISM Minimum Frequency: 2.41 GHz
ISM Maximum Frequency: 2.47 GHz
UNII Minimum Frequency: 5.18 GHz
UNII Maximum Frequency: 5.70 GHz
Antenna Gain: 4 dBi
Antenna Type: Omnidirectional Antenna
Wireless Transmission Speed: 450 Mbps
Wireless Security: •EAP-MSCHAPv2
•IEEE 802.1X
•IEEE 802.11i
•MSCHAPv2
•EAP-TTLS
•EAP-TLS
•WPA2
•PEAP
•WPA
•TKIP
•AES

Features: MIMO Technology

AIR-CAP2602I-E-K9 Interfaces/Ports
Ethernet Port: Yes
Fast Ethernet Port: Yes
Gigabit Ethernet Port: Yes
10Gigabit Ethernet Port: No
Number of Network (RJ-45) Ports: 1
Network (RJ-11): No
PoE (RJ-45) Port: No
VGA: No
HDMI: No
Audio Line Out: No
Serial Port: No
USB: No
Powerline: No
Management Port: Yes

AIR-CAP2602I-E-K9 Power Description
Input Voltage: 57 V DC
  110 V AC
  220 V AC
Power Source: PoE
  Power Supply

AIR-CAP2602I-E-K9 Physical Characteristics
Form Factor: Ceiling Mountable
Height: 2.1"
Width: 8.7"
Depth: 8.7"
Weight (Approximate): 2.30 lb
