AIR-AP1252AG-A-K9

Manufacturer Part#: Cisco  AIR-AP1252AG-A-K9
AIR-AP1252AG-A-K9 Cisco Wireless Points (AP)

AIR-AP1252AG-A-K9 Specification:
Wireless Access Point - 600Mbps

Data Sheet Download: Cisco Aironet 1250 Series Access Point.pdf

Cisco Aironet 1252 is the first enterprise class access point to support the IEEE 802.11n draft 2.0 standard. 802.11n offers combined data rates of up to 600 Mbps to provide users with mobile access to high-bandwidth data, voice, and video applications regardless of their location. Through the use of multiple-input multiple-output (MIMO) technology, 1252 also provides reliable and predictable WLAN coverage to improve the end-user experience for both existing 802.11a/b/g clients and new 802.11n clients.


Cisco AIR-AP1252AG-A-K9 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Line: Aironet
Product Series: 1250
Product Model: 1252
Product Name: Aironet 1252 Wireless Access Point
Packaged Quantity: 1
Product Type: Wireless Access Point

Cisco AIR-AP1252AG-A-K9 Technical Information:
Wi-Fi Standard: IEEE 802.11n (draft)
ISM Band: Yes
UNII Band: Yes
ISM Minimum Frequency: 2.41 GHz
ISM Maximum Frequency: 2.46 GHz
UNII Minimum Frequency: 5.15 GHz
UNII Maximum Frequency: 5.32 GHz
Number of Antennas: 6
Antenna Gain: 10 dBi
Antenna Connector: RP-TNC Connector
Channels: 8 Channel Maximum Operating IEEE 802.11a America (FCC)
Channels: 11 Channel Maximum Operating IEEE 802.11b/g America (FCC)
Wireless Transmission Speed: 600 Mbps
Transmission Speed Details: 600Mbps
Transmission Speed Details: 54Mbps Auto-fallback IEEE 802.11a/g
Transmission Speed Details: 6Mbps IEEE 802.11a/g
Transmission Speed Details: 11Mbps Auto-fallback IEEE 802.11b
Transmission Speed Details: 1Mbps IEEE 802.11b
Modulation:

•OFDM
•DSSS

Cisco AIR-AP1252AG-A-K9 Interfaces/Ports:
Number of Ports: 1
Gigabit Ethernet Port: Yes
Interfaces/Ports: 1 x RJ-45 Console Management
Interfaces/Ports: 1 x RJ-45 10/100/1000Base-T LAN

Cisco AIR-AP1252AG-A-K9 Management & Protocols:
•Command Line Interface (CLI)
•Browser based management
•DHCP
•Simple Network Management Protocol (SNMP)

Security Features:
•EAP-Transport Layer Security (TLS)
•AES
•EAP-Tunneled TLS(TTLS)/Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)

Cisco AIR-AP1252AG-A-K9 Power Description:
Input Voltage: 220 V AC
Input Voltage: 110 V AC
Input Voltage Range: 36V DC to 57V DC
Input Voltage Range: 100V AC to 240V AC
Power Source: Power Supply

Cisco AIR-AP1252AG-A-K9 Physical Characteristics:
Form Factor: Desktop
Form Factor: Ceiling-mountable
Dimensions: 2.35 Height x 8.12 Width x 9.52 Depth
Weight: 5.1 lb
Weight: 2.1 lb
