AIR-AP1041N-E-K9

Manufacturer Part#: Cisco AIR-AP1041N-E-K9
Cisco Aironet 1041n Wireless Access Point AIRAP1041NEK9
Cisco Aironet 1041N Standalone Wireless-N Access Point (300Mbps) AIR-AP1041N-E-K9

Cisco AIR-AP1041N-E-K9 300 Mbps Wireless LAN Access Point

AIR-AP1041N-E-K9
300 Mbit/s (max) data transfer rate
Ethernet LAN (RJ-45) ports quantity: 1
Security algorithms supported: WPA, WPA2, WPA-AES, WPA-TKIP, EAP, 802.1x RADIUS
Frequency band: 2.4/5 GHz
LED indicators: WLAN

AIR-AP1041N-E-K9
Part Code: AIR-AP1041N-E-K9
•Manufacturer: Cisco
•Device Type: Radio access point
•Form Factor: External
•Localisation: Belgium, Jordan, Kuwait, Oman, Qatar, Saudi Arabia, Bulgaria, China, Czech Republic, Estonia, Israel, Lithuania, South Africa, Vietnam, Ukraine, Iceland, Pakistan, Romania, Thailand, Singapore, Luxembourg, Hungary, Cyprus, Iraq, Nigeria, Algeria, Liechtenstein, Gibraltar, Malta, Monaco, Tunisia, Belarus, Bosnia, Croatia, Macedonia, Slovakia, Slovenia, Korea, Latvia, Herzegovina, Austria, Denmark, Finland, France, Germany, Italy, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland, United Kingdom, Greece, Turkey, Ireland, Serbia, Montenegro
•RAM: 128 MB

AIR-AP1041N-E-K9 Description
The Cisco Aironet 1040 Series Access Point is an enterprise-class, entry-level 802.11n access point designed to address the wireless connectivity needs of small and medium-sized enterprises

AIR-AP1041N-E-K9 Product Features
•Business ready 802.11n performance
With 2x2 multiple-input multiple-output (MIMO) technology providing at least six times the throughput of existing 802.11a/g networks, the Cisco Aironet 1040 Series offers the performance advantage of 802.11n enterprise-class quality at an entry-level price for small and medium-sized enterprises.
•RF excellence
Building on the Cisco Aironet heritage of RF excellence, the 1040 Series delivers secure and reliable wireless connections. Enterprise-class chipsets and optimized radios deliver a robust mobility experience.
•Environmentally responsible
Designed for sustainability, the Cisco Aironet 1040 Series offers 802.11n performance with standard 802.3af Power over Ethernet (PoE). At only 12.95 watts of power, the 1040 Series combines the power of dual-radio 802.11n with the efficiency of standard PoE. The sleek industrial design of the 1040 Series blends seamlessly into any indoor enterprise environment.

AIR-AP1041N-E-K9 Product Details
Device Type Radio access point
Form Factor External
Localisation Belgium, Jordan, Kuwait, Oman, Qatar, Saudi Arabia, Bulgaria, China, Czech Republic, Estonia, Israel, Lithuania, South Africa, Vietnam, Ukraine, Iceland, Pakistan, Romania, Thailand, Singapore, Luxembourg, Hungary, Cyprus, Iraq, Nigeria, Algeria, Liechtenstein, Gibraltar, Malta, Monaco, Tunisia, Belarus, Bosnia, Croatia, Macedonia, Slovakia, Slovenia, Korea, Latvia, Herzegovina, Austria, Denmark, Finland, France, Germany, Italy, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland, United Kingdom, Greece, Turkey, Ireland, Serbia, Montenegro
RAM 128 MB
Flash Memory 32 MB
Data Link Protocol IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Frequency Band 2.4 GHz
Power Over Ethernet (PoE) Supported PoE

AIR-AP1041N-E-K9 Dimensions (WxDxH) 22.1 cm x 22.1 cm x 4.7 cm
Weight 1.04 kg
Manufacturer Warranty Limited lifetime warranty

AIR-AP1041N-E-K9 Software
•Cisco Unified Wireless Network Software Release 7.0 or later
•Cisco IOS Software Release 12.4(21a)JA

AIR-AP1041N-E-K9 Data Rates Supported
•802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
•802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
•802.11n data rates 300 Mbps

AIR-AP1041N-E-K9 802.11n Capabilities
•Maximal ratio combining (MRC)
•20- and 40-MHz channels
•PHY data rates up to 300 Mbps
•Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
•802.11 dynamic frequency selection (DFS) (Bin 5)
•Cyclic shift diversity (CSD) support

AIR-AP1041N-E-K9  Integrated Antenna
•2.4 GHz, Gain 4.0 dBi, horizontal beamwidth 360°

AIR-AP1041N-E-K9  Interfaces
•10/100/1000BASE-T autosensing (RJ-45)
•Management console port (RJ45)

AIR-AP1041N-E-K9 Indicators
•Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors

AIR-AP1041N-E-K9 Dimensions (W x L x H)
•Access point (without mounting bracket): 8.7 x 8.7 x 1.84 in. (22.1 x 22.1 x 4.7 cm)

Weight
•2.3 lbs (1.04 kg)

AIR-AP1041N-E-K9 Environmental
•Nonoperating (storage) temperature: -22 to 185°F (-30 to 85°C)
•Operating temperature: 32 to 104°F (0 to 40°C)
•Operating humidity: 10 to 90% percent (non-condensing)

AIR-AP1041N-E-K9 System Memory•128 MB DRAM
•32 MB flash

AIR-AP1041N-E-K9 Input Power Requirements
•44 to 57 VDC
•Power Supply and Power Injector: 100 to 240 VAC; 50 to 60 Hz

AIR-AP1041N-E-K9 Powering Options
•802.3af Ethernet Switch
•Cisco AP1140 Power Injectors (AIR-PWRINJ4=)
•Cisco AP1140 Local Power Supply (AIR-PWR-B=)

AIR-AP1041N-E-K9 Power Draw
•12.95 W

AIR-AP1041N-E-K9 Warranty
•Limited Lifetime Hardware Warranty

AIR-AP1041N-E-K9 Safety
•UL 60950-1
•CAN/CSA-C22.2 No. 60950-1
•UL 2043
•IEC 60950-1
•EN 60950-1

AIR-AP1041N-E-K9 Radio approvals
•FCC Part 15.247, 15.407
•EN 300.328, EN 301.893 (Europe)
•EMI and susceptibility (Class B)
•FCC Part 15.107 and 15.109
•EN 301.489-1 and -17 (Europe)
•EN 60601-1-2 EMC requirements for the Medical Directive 93/42/EEC
IEEE Standard
•IEEE 802.11a/b/g, IEEE 802.11n, IEEE 802.11h, IEEE 802.11d

AIR-AP1041N-E-K9 Security
•802.11i, Wi-Fi Protected Access 2 (WPA2), WPA 802.1X
•Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)

AIR-AP1041N-E-K9 EAP Type(s)
•Extensible Authentication Protocol-Transport Layer Security (EAP-TLS)
•EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
•Protected EAP (PEAP) v0 or EAP-MSCHAPv2
•Extensible Authentication Protocol-Flexible Authentication via Secure Tunneling (EAP-FAST)
•PEAPv1 or EAP-Generic Token Card (GTC)
•EAP-Subscriber Identity Module (SIM)

AIR-AP1041N-E-K9 Multimedia
•Wi-Fi Multimedia (WMM)

AIR-AP1041N-E-K9 Other
•FCC Bulletin OET-65C
•RSS-102

AIR-AP1041N-E-K9 Calculated Mean Time Between Failure (MTBF)
•390,000 hours

AIR-AP1041N-E-K9 General Information
Manufacturer: Cisco
Product ID: AIR-AP1041N-E-K9
Product Description: 802.11g/n Fixed Auto AP; Int Ant; E Reg Domain
Product Type: Wireless Access Point
Marketing Information
Designed for sustainability, the Cisco Aironet 1040 Series offers 802.11n performance with standard 802.3af Power over Ethernet (PoE). At only 12.95 watts of power, the 1040 Series combines the power of dual-radio 802.11n with the efficiency of standard PoE. The sleek industrial design of the 1040 Series blends seamlessly into any indoor enterprise environment.

AIR-AP1041N-E-K9 Technical Information
Wi-Fi Standard: IEEE 802.11n
ISM Band: Yes
UNII Band: No
ISM Minimum Frequency: 2.41 GHz
ISM Maximum Frequency: 2.47 GHz
Antenna Gain: 4 dBi
Wireless Transmission Speed: 300 Mbps
Wireless Security: •WPA
•WPA 2
•AES
•TKIP
•TTLS
•EAP-TLS
•MSCHAP v2
•EAP
•PEAP
•EAP-MSCHAP v2
•EAP-FAST

AIR-AP1041N-E-K9 Interfaces/Ports
Ethernet Port: Yes
Fast Ethernet Port: Yes
Gigabit Ethernet Port: Yes
Number of Network (RJ-45) Ports: 1
Network (RJ-11): No
PoE (RJ-45) Port: No
Powerline: No
Management Port: Yes
Power Description
Power Source: PoE

Contact Sea Tel International for more information.
