HOME PRODUCT Cisco Wireless Access Points AIR-AP1131AG-C-K9
Categories
AIR-AP1131AG-C-K9
AIR-AP1131AG-C-K9

AIR-AP1131AG-C-K9

Product ID : Cisco Wireless AP
Product Description
Manufacturer Part#: Cisco  AIR-AP1131AG-C-K9
AIR-AP1131AG-C-K9
Cisco Wireless AP

AIR-AP1131AG-C-K9 - Dual frequency 2.4G and 5.8G   54M In-built antenna Fat AP
802.11a, .11g AP, Int Radios, Ants, China Cnfg

In stock & Ready to ship

Cisco Aironet AIR-AP1131AG IEEE 802.11a/b/g Access Point provide high-capacity, high-security, enterprise-class features in an unobtrusive, office-class design, delivering WLAN access with the lowest total cost of ownership. Two high-performing radios provide simultaneous support for 802.11a and 802.11g standards, delivering 108 Mbps data rates in the 5 and 2.4 GHz bands to distances surpassing that of previous-generation radios. For smooth migration, the Cisco Aironet AIR-AP1131AG IEEE 802.11a/b/g Access Point takes full advantage of the dual-band capabilities of today's WLAN clients, while providing full backward compatibility for legacy 802.11b clients.

Cisco AIR-AP1131AG-C-K9 General Information
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Line: Aironet
Product Series: 1100
Product Model: AIR-AP1131AG
Product Name: Aironet 1130AG Access Point
Product Type: Wireless Access Point

Cisco AIR-AP1131AG-C-K9 Technical Information
Wi-Fi Standard: IEEE 802.11a/b/g
ISM Band: Yes
UNII Band: Yes
ISM Minimum Frequency: 2.41 GHz
ISM Maximum Frequency: 2.4 GHz
UNII Minimum Frequency: 5.15 GHz
UNII Maximum Frequency: 5 GHz
Number of Antennas: 2
Antenna Gain: 3 dBi
Antenna Gain: 4.5 dBi
Antenna Type: Omni-directional Antenna
Indoor Antenna Range: 450 ft
Outdoor Antenna Range: 950 ft
Channels: 4 Channel Operating IEEE 802.11a China
Channels: 13 Channel Operating IEEE 802.11b/g China
Channels: 3 Channel Non-overlapping IEEE 802.11b/g America (FCC)
Channels: 19 Channel Non-overlapping IEEE 802.11a America (FCC)
Channels: 12 Channel Operating IEEE 802.11a America (FCC)
Channels: 11 Channel Operating IEEE 802.11b/g America (FCC)
Wireless Transmission Speed: 108 Mbps
Transmission Speed Details: 54Mbps Auto-fallback IEEE 802.11a/g
Transmission Speed Details: 108Mbps 2x Mode
Transmission Speed Details: 1Mbps IEEE 802.11b
Transmission Speed Details: 11Mbps Auto-fallback IEEE 802.11b
Transmission Speed Details: 6Mbps IEEE 802.11a/g
Transmit Power: 20 dBm

Cisco AIR-AP1131AG-C-K9 Interfaces/Ports
Number of Ports: 1
Fast Ethernet Port: Yes
Interfaces/Ports: 1 x RJ-45 Console Management
Interfaces/Ports: 1 x RJ-45 10/100Base-TX Uplink

Cisco AIR-AP1131AG-C-K9 Management & Protocols
Management:
BootP
Secure Shell (SSH) Protocol
Secure HTTP (HTTPS)
Trivial File Transfer Protocol (TFTP)
FTP
Telnet
Console port
Simple Network Management Protocol (SNMP) MIB I and MIB II
CiscoWorks Resource Manager Essentials (RME)
CiscoWorks Software Image Manager (SWIM)
CiscoWorks Campus Manager
CiscoWorks CiscoView
CiscoWorks WLSE
BootP
Secure Shell (SSH) Protocol
Secure HTTP (HTTPS)
Trivial File Transfer Protocol (TFTP)
FTP
Telnet
Console port
Simple Network Management Protocol (SNMP) MIB I and MIB II
CiscoWorks Resource Manager Essentials (RME)
CiscoWorks Software Image Manager (SWIM)
CiscoWorks Campus Manager
CiscoWorks CiscoView
CiscoWorks WLSE

Cisco AIR-AP1131AG-C-K9 Power Description
Input Voltage: 220 V AC
Input Voltage: 110 V AC
Input Voltage Range: 100V AC to 240V AC
Input Voltage Range: 36V DC to 57V DC
Power Source: Power Supply

Cisco AIR-AP1131AG-C-K9 Environmental Conditions
Temperature: 0 degrees C (32.0 degrees F) 40 degrees C (104.0 degrees F) Operating

Cisco AIR-AP1131AG-C-K9 Physical Characteristics
Form Factor: Ceiling-mountable
Form Factor: Wall-mountable
Dimensions: 7.52 Height x 7.52 Width x 1.3 Depth
Weight: 1.48 lb

Sea Tel International Co., Limited Cisco Wireless AP Stock
www.sea-tel.com 852 23892981 [email protected]
Part# Product Description Stock
AIR-AP1131G-E-K9 Single Frequency 2.4G 54M In-built antenna Fat AP In stock&Ready to ship
AIR-LAP1131G-E-K9 Single Frequency 2.4G 54M In-built antenna Slim AP In stock&Ready to ship
AIR-AP1131AG-C-K9 Dual frequency 2.4G and 5.8G   54M In-built antenna Fat AP In stock&Ready to ship
AIR-LAP1131AG-C-K9 Dual frequency 2.4G and 5.8G   54M In-built antenna Slim AP In stock&Ready to ship
AIR-LAP1242AG-C-K9 Dual frequency 2.4G and 5.8G   54M    Slim AP In stock&Ready to ship
AIR-AP1242AG-C-K9 Dual frequency 2.4G and 5.8G   54M    Fat AP In stock&Ready to ship
AIR-LAP1242G-E-K9 Single Frequency 2.4G 54M    Slim AP In stock&Ready to ship
AIR-AP1242G-E-K9 Single Frequency 2.4G 54M    Fat AP In stock&Ready to ship
 300M   AP
AIR-AP1141N-E-K9 Single Frequency 2.4G         300M In-built antenna Fat AP   In stock&Ready to ship
AIR-AP1142N-C-K9 Dual frequency 2.4G and 5.8G   300M In-built antenna Fat AP   In stock&Ready to ship
AIR-LAP1142N-C-K9 Dual frequency 2.4G and 5.8G   300M In-built antenna Slim AP   In stock&Ready to ship
AIR-AP1252AG-C-K9 Dual frequency 2.4G and 5.8G   300M    Fat AP   In stock&Ready to ship
AIR-LAP1252AG-C-K9 Dual frequency 2.4G and 5.8G   300M    Slim AP   In stock&Ready to ship
AIR-AP1042N-C-K9 Dual frequency 2.4G and 5.8G   300M In-built antenna Fat AP   In stock&Ready to ship
AIR-LAP1041N-E-K9 Single Frequency 2.4G         300M In-built antenna Slim AP   In stock&Ready to ship
AIR-LAP1262N-C-K9 Dual frequency 2.4G and 5.8G   300M    Slim AP   In stock&Ready to ship
AIR-AP1262N-C-K9 Dual frequency 2.4G and 5.8G   300M    Fat AP   In stock&Ready to ship
AIR-CAP3502I-C-K8 Dual frequency 、300M,In-built antenna on Controller 802.10a/g/n In stock&Ready to ship
AIR-CAP3502I-A-K9 Dual frequency 、300M,In-built antenna on Controller 802.11a/g/n  In stock&Ready to ship
AIR-CAP3502E-C-K9 Dual frequency 、 on Controller 802.11a/g/n  In stock&Ready to ship
AIR-CAP3602I-C-K9 Dual frequency 、300M,In-built antenna on Controller 802.11a/g/n  In stock&Ready to ship
AIR-AP1310G-A-K9 Single Frequency 2.4G 54M wirelessAP In-built antenna In stock&Ready to ship
AIR-AP1310G-A-K9-R Single Frequency 2.4G 54M wirelessAP   In stock&Ready to ship
 network bridge
AIR-BR1310G-A-K9 Single Frequency 2.4G 54M wireless network bridge In-built antenna In stock&Ready to ship
AIR-BR1310G-A-K9-R Single Frequency 2.4G 54M wireless network bridge    In stock&Ready to ship
AIR-BR1410A-A-K9-N Single Frequency 5.8G 54M wireless network bridge    In stock&Ready to ship
AIR-BR1410A-A-K9 Single Frequency 5.8G 54M wireless network bridge In-built antenna In stock&Ready to ship
Accessories
AIR-PWRINJ4 Power supply In stock&Ready to ship
AIR-PWRINJ3 1100, 1130AG, 1200 1230AG, 1240AG,  In stock&Ready to ship
AIR-ANT5135D-R 5。8G 2.2dbi Antenna, can receive signal from all 5.8G AP In stock&Ready to ship
AIR-ANT1728 2.4G 5.2dbi Antenna, can receive signal from all 2.4G AP In stock&Ready to ship
AIR-ANT4941 2.4G 2.2dbi Antenna, can receive signal from all 2.4G AP In stock&Ready to ship
AIR-ANT5959 2.4G 2dbi Antenna, can receive signal from all 2.4G AP In stock&Ready to ship
AIR-ANT2422DG-R 2.4G antenna  antenna   In stock&Ready to ship
AIR-ANT5135DW-R antenna 5G antenna  In stock&Ready to ship
AIR-ACCBRGB=  wireless network bridge  In stock&Ready to ship
AIR-ACC245LA-R  antenna ;weight:200g,TNC-R In stock&Ready to ship
AIR-ANT1949 2.4 GHz, 13.5 dBi In stock&Ready to ship
AIR-CAB020DRG6-F= 20 inch equivalent to 6 m   r-f line  In stock&Ready to ship
AIR-CAB050DRG6-F= 50 inch equivalent to 15 m   r-f line  In stock&Ready to ship
AIR-CAB100DRG6-F 100 inch equivalent to 30 m   r-f line  In stock&Ready to ship
AIR-ACCRMK1300= Used on AIR-BR1310G-A-K9 In stock&Ready to ship
CONTROLLER
AIR-WLC2106-K9  wireless controller, can manager 6 pcs AP  In stock&Ready to ship
AIR-WLC2112-K9  wireless controller, can manager 12 pcs AP In stock&Ready to ship
AIR-WLC2125-K9  wireless controller, can manager 25 pcs AP In stock&Ready to ship
AIR-CT2504-5-K9  wireless controller, can manager 5 pcs AP  In stock&Ready to ship
AIR-CT2504-15-K9  wireless controller, can manager 15 pcs AP  In stock&Ready to ship
AIR-CT2504-25-K9  wireless controller, can manager 25 pcs AP  In stock&Ready to ship
AIR-CT2504-50-K9  wireless controller, can manager 50 pcs AP  In stock&Ready to ship
AIR-CT5508-12-K9  wireless controller, can manager 12 pcs AP  In stock&Ready to ship
AIR-CT5508-25-K9  wireless controller, can manager 25 pcs AP  In stock&Ready to ship
AIR-CT5508-50-K9  wireless controller, can manager 50 pcs AP  In stock&Ready to ship

Contact Sea Tel International Co., Limited for more information.
