Product Description
Manufacturer Part#: Cisco 12000-SIP-501
12000-SIP-501 Cisco Interface & Line Card
12000-SIP-501 - 4 x Port Adapter - Interface Processor
In stock and Ready to ship
Cisco XR 12000 and 12000 series SPA Interface Processor 501 provides a common forwarding and queuing engine responsible for packet classification, forwarding decisions, packet queuing, and accounting without compromising the performance. It has two forwarding engines, one for ingress and one for egress, allowing the user to implement multiple features and QoS policies at the incoming traffic, independently from the features and the QoS policies applied at the egress interfaces. The multicast replication is done by the egress forwarding engine, hence a very scalable multicast implementation with a native and built-in security and QoS features for multicast flows.
Cisco 12000-SIP-501 General Information
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: 12000
Product Name: SPA Interface Processor 501
Product Type: Interface Processor
Cisco 12000-SIP-501 Interfaces/Ports
Interfaces/Ports: Not Applicable
Interfaces/Ports Details: Not Applicable
Cisco 12000-SIP-501 I/O Expansions
Expansion Slots: 4 x Port Adapter
12000-SIP-501 Physical Characteristics
Dimensions: 1.8 Height x 16 Width x 20.62 Depth
Weight: 12.2 lb - without SPAs
Weight: 15.2 lb - with 4 SPAs
Cisco 12000 SIP-501 Physical Specifications
12000-SIP-501 Cisco Interface & Line Card
12000-SIP-501 - 4 x Port Adapter - Interface Processor
In stock and Ready to ship
Cisco XR 12000 and 12000 series SPA Interface Processor 501 provides a common forwarding and queuing engine responsible for packet classification, forwarding decisions, packet queuing, and accounting without compromising the performance. It has two forwarding engines, one for ingress and one for egress, allowing the user to implement multiple features and QoS policies at the incoming traffic, independently from the features and the QoS policies applied at the egress interfaces. The multicast replication is done by the egress forwarding engine, hence a very scalable multicast implementation with a native and built-in security and QoS features for multicast flows.
Cisco 12000-SIP-501 General Information
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: 12000
Product Name: SPA Interface Processor 501
Product Type: Interface Processor
Cisco 12000-SIP-501 Interfaces/Ports
Interfaces/Ports: Not Applicable
Interfaces/Ports Details: Not Applicable
Cisco 12000-SIP-501 I/O Expansions
Expansion Slots: 4 x Port Adapter
12000-SIP-501 Physical Characteristics
Dimensions: 1.8 Height x 16 Width x 20.62 Depth
Weight: 12.2 lb - without SPAs
Weight: 15.2 lb - with 4 SPAs
Cisco 12000 SIP-501 Physical Specifications
| Description | Specifications |
| Physical dimensions | Occupies one line card slot on a Cisco 12000 Series Router |
| Shipping weight | 10kg |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Relative humidity | 10 to 90 percent, noncondensing |
| Storage temperature | –4 to 149°F (–20 to 65°C) |
| SIP Engine Processor | ||
| Product Number | Description | Engine Type |
| 12000-SIP-400 | 2.5G ISE SPA Interface Processor | Engine 3 (ISE) |
| 12000-SIP-600 | 10G Engine 5 SPA Interface Processor | Engine 5 |
| 12000-SIP-401 | 2.5G Engine 5 SPA Interface Processor | Engine 5 |
| 12000-SIP-501 | 5G Engine 5 SPA Interface Processor | Engine 5 |
| 12000-SIP-601 | 10G Engine 5 SPA Interface Processor | Engine 5 |
