VS-S2T-10G-XL

Manufacturer Par#: Cisco VS-S2T-10G-XL
VS-S2T-10G-XL Cisco Catalyst 6500 Series Supervisor Engine 2T XL - control processor

The Cisco Catalyst 6500 Supervisor Engine 2T is designed to deliver higher performance, better scalability, and enhanced hardware-enabled features. Supervisor Engine 2T integrates a high-performance 2-Terabit crossbar switch fabric that enables 80 Gbps switching capacity per slot on all Cisco Catalyst 6500 E-series chassis. The forwarding engine on Supervisor Engine 2T is capable of delivering high-performance forwarding for Layer 2 and Layer 3 services. Supervisor Engine 2T delivers many hardware-enabled innovations in the areas of security, quality of service (QoS), virtualization, and manageability. The rich feature set of Supervisor Engine 2T enhances applications such as traditional IP forwarding, Layer 2 and Layer 3 Multi-protocol Label Switching (MPLS) VPNs, and VPLS.

VS-S2T-10G-XL Product Features
•Platform scalability
Delivering up to 80 Gbps per slot of switching capacity on E-Series chassis; 2-Terabit aggregate bandwidth capacity, scaling to 4-Terabit capacity with VSS. Support for up to 1056 ports of 1 Gbps and 352 ports of 10 Gbps systems deployed with VSS. Providing 1 Gbps/10 Gbps and 40 Gbps interface support to address future customer bandwidth growth requirements.
•Virtualization
Native support for VPLS, as well as enhancements such as VPN-aware NAT, VPN statistics, and VPN netflow as important features needed for deployment of network virtualization.
•Netflow application monitoring
Supervisor Engine 2T supports enhanced application monitoring such as flexible and sampled netflow for intelligent and scalable application monitoring.

VS-S2T-10G-XL Specifications
1.Brand:CISCO
2.Type:cisco switch
3.Model no.:  CISCO VS-S2T-10G-XL cisco module
4.Feature:      Cat 6500 Supervisor 720 with 2 x 10GbE and 3x1GE MSFC3 PFC3CXL

VS-S2T-10G-XL General specifications
Manufacturer Cisco
Manufacturer Part # cisco engine VS-S2T-10G-XL=
Cost Central Item # 11584476
Product Description Cisco Catalyst 6500 Series Supervisor Engine 2T - Control processor - 10 Gigabit LAN - plug-in module - for Catalyst 6503-E, 6504-E, 6506-E, 6506-E IDSM-2, 6509-E, 6509-E 10Gig, 6509-V-E, 6513-E
Device Type Control processor
Form Factor Plug-in module
RAM 2 GB (installed) / 4 GB (max)
Flash Memory 1 GB
Data Link Protocol 10 Gigabit Ethernet
Performance IPv4 routing : 720 Mpps
IPv6 routing : 390 Mpps
Capacity MAC addresses : 128000
IPv4 routes : 256000
IPv6 routes : 128000
NetFlow entries : 512000
Virtual interfaces (VLANs) : 4000
Multicast entries (IPv4) : 128000
Multicast entries (IPv6) : 128000
Approximate Dimensions (WxDxH) 14.4 in x 16 in x 1.7 in
Approximate Weight 11.9 lbs
Manufacturer Warranty 90 days warranty

VS-S2T-10G-XL Designed For:
Catalyst 6503-E, 6504-E, 6506-E, 6506-E IDSM-2, 6509-E, 6509-E 10Gig, 6509-V-E, 6513-E

VS-S2T-10G-XL Networking and expansion
Form Factor Plug-in module
Connectivity Technology Wired
Data Link Protocol 10 Gigabit Ethernet
Performance IPv4 routing : 720 Mpps
IPv6 routing : 390 Mpps
Capacity MAC addresses : 128000
IPv4 routes : 256000
IPv6 routes : 128000
NetFlow entries : 512000
Virtual interfaces (VLANs) : 4000
Multicast entries (IPv4) : 128000
Multicast entries (IPv6) : 128000
Features Layer 3 switching, layer 2 switching, NAT support, VPN support, MPLS support, IGMP snooping, IPv6 support, Access Control List (ACL) support, Quality of Service (QoS), MPLS VPN, IPv4 support, NetFlow
Compliant Standards IEEE 802.1x
Supported Flash Memory Cards CompactFlash Card
Expansion Slots 3 (total) / 3 (free) x SFP (mini-GBIC)
2 (total) / 2 (free) x X2

VS-S2T-10G-XL Interfaces
1 x 1000Base-T (management) - RJ-45
1 x management - RJ-45
1 x USB - Type A
1 x USB - Type B
Compatible Slots 1 x expansion slot

VS-S2T-10G-XL Part Code: VS-S2T-10G-XL
•Manufacturer: Cisco
•Device Type: Control processor
•Form Factor: Plug-in module
•RAM: 4 GB
•Flash Memory: 1 GB

VS-S2T-10G-XL Manufacturer Cisco Systems, Inc
Manufacturer Part Number VS-S2T-10G-XL
Brand Name Cisco
Product Model 2T
Product Name 2T Supervisor Engine
Marketing Information Supervisor Engine 2T delivers scalable performance, intelligence, and a broad set of features to address the needs of Borderless Networks, data centers, and service provider networks.

VS-S2T-10G-XL Product Type Supervisor Engine
Application/Usage •Optical Network
•Data Networking

VS-S2T-10G-XL Interfaces/Ports Details
•1 x RJ-45 10/100/1000Base-T Network Management
•1 x RJ-45 Console Management
•1 x USB

VS-S2T-10G-XL Expansion Slots
•3 x SFP (mini-GBIC)
•2 x X2

VS-S2T-10G-XL Dimensions
1.7" Height x 14.4" Width x 16.0" Depth
Weight (Approximate) 12.00 lb
Compatibility Catalyst 6500 Series Switch Chassis

VS-S2T-10G-XL Technical Information
Application/Usage  Data Networking
Application/Usage  Optical Network

VS-S2T-10G-XL Interfaces/Ports
Interfaces/Ports Details  1 x RJ-45 10/100/1000Base-T Network Management
Interfaces/Ports Details  1 x USB
Interfaces/Ports Details  1 x RJ-45 Console Management

VS-S2T-10G-XL I/O Expansions
Expansion Slots  3 x SFP (mini-GBIC)
Expansion Slots  2 x X2
Management & Protocols
Management  •Cisco Works
•VLAN
•QoS

VS-S2T-10G-XL Physical Characteristics
Dimensions  1.7" Height x 14.4" Width x 16.0" Depth
Weight (Approximate)  12.00 lb

VS-S2T-10G-XL Miscellaneous
Compatibility  Catalyst 6500 Series Switch Chassis

Cisco Supervisor 2T with 2 ports 10GbE and MSFC5 PFC4XL.
Supervisor Engine 2T delivers scalable performance, intelligence, and a broad set of features to address the needs of Borderless Networks, data centers, and service provider networks. Some of the primary features for Supervisor Engine 2T include:
• Platform scalability: Delivering up to 80 Gbps per slot of switching capacity on E-Series chassis; 2-Terabit aggregate bandwidth capacity using the 6513-E chassis, scaling to 4-Terabit capacity with VSS. Support for up to 1056 ports of 1Gbps and 352 ports of 10Gbps systems deployed with VSS. Providing 1Gbps/10Gbps and 40Gbps interface support to address future customer bandwidth growth requirements.
• Security: Support for Cisco TrustSec, CTS, providing MacSec encryption and Role-Based ACL. Providing control plane policing to address denial of service attacks.
• Virtualization: Native support for VPLS, as well as enhancements such as VPN-aware NAT, VPN statistics, and VPN netflow as important features needed for deployment of network virtualization.
• Netflow application monitoring: Supervisor Engine 2T supports enhanced application monitoring such as Flexible and Sampled Netflow for intelligent and scalable application monitoring.

Contact Sea Tel International for more information
