CSS-11154-256M-AC

Manufacturer Part#: Cisco CSS-11154-256M-AC
CSS-11154-256M-AC Content Services Switches (CSS)

CSS-11154-256M-AC -  CSS 11154, 12 pt FE (TX), 2 pt GE (SX w/8MB), 256MB, HD, AC

Cisco CSS-11154-256M-AC Miscellaneous:
•Slot configuration: Fixed
•Delivers up to 400 percent improvement in Web cache efficiency for transparent, proxy, and reverse proxy configurations

Certifications & Standards: Safety:
•UL 1950
•CSA 950
•EN60950
•GS Mark

EMC:
•FCC Part 15 Class A
•EN55022 Class A
•EN 50082-1
•VCCI Class 1

Factory approvals:
•UL
•TUV
•BABT 340

Cisco CSS-11154-256M-AC Original Manufacturer Warranty:

Standard Warranty: 1 Year Limited
Additional Warranty Information: Replacement, Repair or Refund Procedure for Hardware: Cisco or its service center will use commercially reasonable efforts to ship a replacement part within ten (10) working days after receipt of the RMA request. Actual delivery times may vary depending on Customer location.

Cisco CSS-11154-256M-AC General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: CSS 11000
Product Name: 11154 Content Switch
Product Type: Content Switch

Cisco CSS-11154-256M-AC Interfaces/Ports:
Number of Ports: 12
Fast Ethernet Port: Yes
Interfaces/Ports: 1 x RJ-45 10/100Base-TX Management
Interfaces/Ports: 1 x RJ-45 Console Management
Interfaces/Ports: 1 x RJ-45 Serial Management
Interfaces/Ports: 2 x RJ-45 1000Base-SX
Interfaces/Ports: 12 x RJ-45 10/100Base-TX LAN

Cisco CSS-11154-256M-AC Media & Performance:
Connectivity Media: Twisted Pair 10/100Base-TX
Connectivity Media: Fiber 1000Base-SX
Performance: 5Gbps Bandwidth

Cisco CSS-11154-256M-AC I/O Expansions:
Modules: Not Applicable

Cisco CSS-11154-256M-AC Network & Communication:
Address Table: Not Applicable

Cisco CSS-11154-256M-AC Management & Protocols:
Manageable: Yes
Management:

•Cisco Web NS Software
•Powerful command line interface (CLI)
•A graphical user interface (GUI)
•Simple Network Management Protocol (SNMP)
•Remote monitoring (RMON)
•Log files

Protocols: TCP/IP
Protocols: LDAP
Protocols: FTP
Security Features:

•Secure socket layer (SSL) session ID
•Wire-speed, per-flow filtering of content requests
•Security policies can be implemented based on any combination of source address, destination address, protocol, type, or content URL
•Intelligent flow inspection prevents common denial of service attacks such as SYN floods, ping floods, and smurfs
•Wire-speed network address translation protects server IP addresses
•Firewall security
•Site-level security with wire-speed denial-of-service (DoS) prevention

Cisco CSS-11154-256M-AC Processor & Chipset:
Processor: 1 x RISC

Cisco CSS-11154-256M-AC Memory:
Standard Memory: 256MB

Cisco CSS-11154-256M-AC Storage:
Storage: Hard Disk

Cisco CSS-11154-256M-AC Controls/Indicators:
•Link activity
•Port transmission speed
•Port duplex mode
•Power

Cisco CSS-11154-256M-AC Power Description
Input Voltage: 220V AC
Input Voltage: 110V AC
Input Current: 3.1 A Maximum
Frequency: 50 Hz or 60 Hz
Power Consumption: 310 W Maximum
Power Source: Power Supply

Cisco CSS-11154-256M-AC Environmental Conditions:
Temperature: -4 degrees F (-20.0 degrees C) to 149 degrees F (65.0 degrees C) Storage
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Humidity: 10% to 95% Non-condensing Relative Humidity Operating

Cisco CSS-11154-256M-AC Physical Characteristics:
Dimensions: 2.62 Height x 17 Width x 15 Depth
Shipping Dimensions: 10 Height x 22 Width x 22 Depth
Weight: 16.1lb
Shipping Weight: 29 lb
