CISCO1548M

Manufacturer Part#: Cisco CISCO1548M
CISCO1548M 8-port autosensing 10/100 managed switch

CISCO1548M:
The Cisco 1548M switch provides the most powerful and cost-effective Fast Ethernet solution in its class. Embedded Simple Network Management Protocol (SNMP) and Remote Monitoring (RMON) capabilities provide management, monitoring, and analysis. A Web-based management interface common to most Cisco stackable LAN products allows network managers to manage a switch from anywhere on the Internet through a standard Web browser. The Cisco 1548M Micro Switch 10/100 also supports four port-based VLANs for enhanced performance, management, and security. And, because management functionality is embedded within the Cisco 1548M, there is no need to purchase additional management modules.

Cisco CISCO1548M General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: 1548M Ethernet Switch
Product Type: Ethernet Switch

Cisco CISCO1548M Interfaces/Ports:
Number of Ports: 8
Fast Ethernet Port: Yes
Interfaces/Ports: 8 x RJ-45 10/100Base-TX LAN
Interfaces/Ports: 1 x RJ-45 Console Management

Cisco CISCO1548M Media & Performance:
Connectivity Media: Category 5 UTP 100Base-TX
Connectivity Media: Category 3, 4, 5 UTP 10Base-T
Performance: 14880pps Forwarding Rate for 64-byte Packet 10Mbps Port
Performance: 148800pps Forwarding Rate for 64-byte Packet 100Mbps Port

Cisco CISCO1548M Network & Communication:
Address Table: 4096 MAC Addresses

Cisco CISCO1548M Management & Protocols:
Manageable: Yes
Management: Management:
•SNMP Management Information Base (MIB) II, Bridge MIB, Ethernet MIB
•Min-RMON MIB (four Groups---Statistics, History, Alarm, and Event)
•CDP supported

•Built-in HTTP server provides easy-to-use Web-based management interface through a standard browser such as Netscape Navigator or Microsoft Explorer. This Web-based management application provides easy-to-use, graphical configuration and monitoring options.
•SNMP and Telnet interface support delivers comprehensive in-band management, and command line interface (CLI)-based management console provides detailed out-of-band management
•Cisco Discovery Protocol (CDP) enables a CiscoView network management station to automatically discover the switch in a network topology
•Manageable through CiscoWorks Windows network management software on a per-port and per-switch basis providing a common management interface for Cisco routers, switches, and hubs
•Support for up to four port-based VLANs for increased LAN performance and security
•RMON software agent supports four RMON groups for enhanced traffic management, monitoring, and analysis
•Switched Port Analyzer (SPAN) port permits high-performance traffic monitoring of a single port from a single network analyzer or RMON probe
•Extensive per-port LEDs for power, port status, speed, and duplex indication provide easy and comprehensive visual management of the system

Protocols: CDP
Protocols: TFTP

Cisco CISCO1548M Memory:
Standard Memory: 4MB

Cisco CISCO1548M Controls/Indicators:
Status Indicators:
PWR

Ports 1 to 8:
Link
Activity
Speed
Full-/half-duplex operation
PWR

Ports 1 to 8:
Link
Activity
Speed
Full-/half-duplex operation

Cisco CISCO1548M Power Description:
Input Voltage: 220V AC
Input Voltage: 110V AC
Power Consumption: 20 W

Cisco CISCO1548M Environmental Conditions:
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Temperature: -40 degrees F (-40.0 degrees C) to 149 degrees F (65.0 degrees C) Storage
Humidity: 10% to 85% Non-condensing Operating
Altitude: 30000 ft Maximum Storage
Altitude: 9840 ft Maximum Operating

Cisco CISCO1548M Physical Characteristics:
Dimensions: 3.1 Height x 11.2 Width x 8.7 Depth
Shipping Dimensions: 13.63 Length x 12 Width x 7.25 Depth
Weight: 3lb
Shipping Weight: 5.96 lb
