C9300-24P-E
C9300-24P-E - Cisco Switch Catalyst 9300
Cisco Catalyst 9300 24-port PoE+, Network Essentials, Cisco 9300 switch
Catalyst 9300 24-port PoE+, Network Essentials
The C9300-24P-E specifications:
- Switching capacity: 128 Gbps
- Forwarding rate: 95.24 Mpps
- Number of ports: 24 10/100/1000 Ethernet PoE+ ports
- Power over Ethernet (PoE) support: Yes, all ports support PoE+ (802.3at)
- PoE power budget: Up to 715W
- Two 10G SFP+ uplink ports
- VLAN support: Yes, with support for up to 4096 VLANs
- Quality of Service (QoS) support: Yes, with support for 8 hardware queues per port
- Security features: Includes 802.1X authentication, DHCP snooping, Dynamic ARP Inspection (DAI), and IP Source Guard
- Management interface: Web-based GUI, Command-Line Interface (CLI), and Simple Network Management Protocol (SNMP) support
- Dimensions (WxDxH): 445 x 454 x 44.5 mm (17.5 x 17.9 x 1.75 inches)
- Weight: 7.25 kg (16 lbs)
- Software image: Cisco IOS XE Software with support for advanced routing protocols and other advanced features
- License: IP Services license (also known as the Enterprise Services license) that unlocks advanced features such as BGP, OSPF, EIGRP, MPLS, and IPv6 routing
Overall, the C9300-24P-E is a high-performance switch suitable for small to medium-sized networks that require PoE+ support and advanced features such as high-speed uplink ports, VLAN support, and security features. Its compact size and advanced capabilities make it suitable for various network setups, including branch offices and enterprise LAN deployments.
