C9300-24S-E
C9300-24S-E Specification |
|
|
Product Code |
C9300-24S-E |
|
Product Description |
Catalyst 9300 24 GE SFP Ports, modular uplink Switch |
|
Total 10/100/1000 or Multigigabit copper ports |
24x 1G SFP |
|
Uplink Configuration |
Modular Uplinks |
|
Default AC power supply |
715W AC |
|
Available PoE power |
N/A |
|
Dimensions (H x W x D) |
1.73 x 17.5 x 17.7 Inches |
|
Cisco StackWise-480 |
Yes |
|
Cisco StackPower |
Yes |
|
Default power supply |
PWR-C1-715WAC-P/2 |
|
Switching capacity |
208 Gbps |
|
Stacking bandwidth |
688 Gbps |
|
Forwarding rate |
154.76 Mpps |
|
Total number of MAC addresses |
32,000 |
|
Total number of IPv4 routes (ARP plus learned routes) |
32,000 (24,000 direct routes and 8000 indirect routes) |
|
IPv4 routing entries |
32,000 |
|
IPv6 routing entries |
16,000 |
|
Multicast routing scale |
8000 |
|
QoS scale entries |
5120 |
|
ACL scale entries |
5120 |
|
Packet buffer per SKU |
16 MB buffer for 24- or 48-port Gigabit Ethernet modelst 32 MB buffer for 24 and 48-port Multigigabit |
|
FNF entries |
64,000 flow on 24- and 48-port Gigabit Ethernet models 128,000 flows on 24-port Multigigabit |
|
DRAM |
8 GB |
|
Flash |
16 GB |
|
VLAN IDs |
4094 |
|
Total Switched Virtual Interfaces (SVIs) |
1000 |
|
Jumbo frames |
9198 bytes |
|
Total routed ports Catalyst per 9300 Series stack |
448 |
|
Wireless bandwidth per switch |
Up to 96 Gbps on 48-port Gigabit Ethernet model |
|
Mean time between failures – MTBF (hours) |
284,130 |
|
Safety certifications
|
•UL 60950-1 •CAN/CSA-C222.2 No. 60950-1 •EN 60950-1 •IEC 60950-1 •AS/NZS 60950.1 •IEEE 802.3 |
| C9300-24P-A | Catalyst 9300 24-port PoE+, Network Advantage |
| C9300-24P-E | Catalyst 9300 24-port PoE+, Network Essentials |
| C9300-24T-A | Catalyst 9300 24-port data only, Network Advantage |
| C9300-24T-E | Catalyst 9300 24-port data only, Network Essentials |
| C9300-48P-A | Catalyst 9300 48-port PoE+, Network Advantage |
| C9300-48P-E | Catalyst 9300 48-port PoE+, Network Essentials |
| C9300-48T-A | Catalyst 9300 48-port data only, Network Advantage |
| C9300-48T-E | Catalyst 9300 48-port data only, Network Essentials |
| C9300-24H-A | Catalyst 9300 24-port UPoE+, Network Advatege |
| C9300-24H-E | Catalyst 9300 24-port UPoE+, Network Essentials |
| C9300-24S-A | Catalyst 9300 24 GE SFP Ports, modular uplink Switch |
| C9300-24S-E | Catalyst 9300 24 GE SFP Ports, modular uplink Switch |
| C9300-24U-A | Catalyst 9300 24-port UPOE, Network Advantage |
| C9300-24U-E | Catalyst 9300 24-port UPOE, Network Essentials |
| C9300-24UX-A | Catalyst 9300 24-port mGig and UPOE, Network Advantage |
| C9300-24UX-E | Catalyst 9300 24-port mGig and UPOE, Network Essentials |
| C9300-48H-A | Catalyst 9300 48-port UPoE+, Network Advantage |
| C9300-48H-E | Catalyst 9300 48-port UPoE+, Network Essentials |
| C9300-48S-A | Catalyst 9300 48 GE SFP Ports, modular uplink Switch |
| C9300-48S-E | Catalyst 9300 48 GE SFP Ports, modular uplink Switch |
| C9300-48U-A | Catalyst 9300 48-port UPOE, Network Advantage |
| C9300-48U-E | Catalyst 9300 48-port UPOE, Network Essentials |
| C9300-48UN-A | Catalyst 9300 48-port of 5Gbps Network Advantage |
| C9300-48UN-E | Catalyst 9300 48-port of 5Gbps Network Essentials |
| C9300-48UXM-A | Catalyst 9300 48-port(12 mGig, 36 2.5Gbps) Network Advantage |
| C9300-48UXM-E | Catalyst 9300 48-port(12 mGig,36 2.5Gbps) Network Essentials |
| C9300-24H-A | Catalyst 9300 24-port UPoE+, Network Advatege |
| C9300-24H-E | Catalyst 9300 24-port UPoE+, Network Essentials |
| C9300-24S-A | Catalyst 9300 24 GE SFP Ports, modular uplink Switch |
| C9300-24S-E | Catalyst 9300 24 GE SFP Ports, modular uplink Switch |
| C9300-24U-A | Catalyst 9300 24-port UPOE, Network Advantage |
| C9300-24U-E | Catalyst 9300 24-port UPOE, Network Essentials |
| C9300-24UX-A | Catalyst 9300 24-port mGig and UPOE, Network Advantage |
| C9300-24UX-E | Catalyst 9300 24-port mGig and UPOE, Network Essentials |
| C9300-48H-A | Catalyst 9300 48-port UPoE+, Network Advantage |
| C9300-48H-E | Catalyst 9300 48-port UPoE+, Network Essentials |
| C9300-48S-A | Catalyst 9300 48 GE SFP Ports, modular uplink Switch |
| C9300-48S-E | Catalyst 9300 48 GE SFP Ports, modular uplink Switch |
| C9300-48U-A | Catalyst 9300 48-port UPOE, Network Advantage |
| C9300-48U-E | Catalyst 9300 48-port UPOE, Network Essentials |
| C9300-48UN-A | Catalyst 9300 48-port of 5Gbps Network Advantage |
| C9300-48UN-E | Catalyst 9300 48-port of 5Gbps Network Essentials |
| C9300-48UXM-A | Catalyst 9300 48-port(12 mGig, 36 2.5Gbps) Network Advantage |
| C9300-48UXM-E | Catalyst 9300 48-port(12 mGig,36 2.5Gbps) Network Essentials |
