Manufacturer Part#: Cisco AIR-CAP2602I-C-K9
AIR-CAP2602I-C-K9
AIR-CAP2602I-C-K9 Manufacturer: Cisco
Product ID: AIR-CAP2602I-C-K9
Product Description: 802.11n CAP w/CleanAir; 3x4:3SS; Mod; Int Ant; C Reg Domain
AIR-CAP2602I-C-K9 General Information
Manufacturer: Cisco
Product ID: AIR-CAP2602I-C-K9
Product Description: 802.11n CAP w/CleanAir; 3x4:3SS; Mod; Int Ant; C Reg Domain
Product Type: Wireless Access Point
Marketing Information
The new Cisco® Aironet® 2600 Series Access Point delivers the most advanced features in its class - with great performance, functionality, and reliability at a great price. The 802.11n based Aironet 2600 Series includes 3x4 MIMO, with three spatial streams, plus Cisco CleanAir™, ClientLink 2.0™, and VideoStream technologies, to help ensure an interference-free, high-speed wireless application experience. Second only to the Cisco Aironet 3600 Series in performance and features, the Aironet 2600 Series sets the new standard for enterprise wireless technology.
AIR-CAP2602I-C-K9 Technical Information
Wi-Fi Standard: IEEE 802.11n
ISM Band: Yes
UNII Band: Yes
ISM Minimum Frequency: 2.41 GHz
ISM Maximum Frequency: 2.47 GHz
UNII Minimum Frequency: 5.75 GHz
UNII Maximum Frequency: 5.83 GHz
Antenna Gain: 4 dBi
Antenna Type: Omnidirectional Antenna
Wireless Transmission Speed: 450 Mbps
Wireless Security: •EAP-MSCHAPv2
•IEEE 802.1X
•IEEE 802.11i
•MSCHAPv2
•EAP-TTLS
•EAP-TLS
•WPA2
•PEAP
•WPA
•TKIP
•AES
AIR-CAP2602I-C-K9 Features: MIMO Technology
Interfaces/Ports
Ethernet Port: Yes
Fast Ethernet Port: Yes
Gigabit Ethernet Port: Yes
10Gigabit Ethernet Port: No
Number of Network (RJ-45) Ports: 1
Network (RJ-11): No
PoE (RJ-45) Port: No
VGA: No
HDMI: No
Audio Line Out: No
Serial Port: No
USB: No
Powerline: No
Management Port: Yes
AIR-CAP2602I-C-K9 Power Description
Input Voltage: 57 V DC
110 V AC
220 V AC
Power Source: PoE
Power Supply
AIR-CAP2602I-C-K9 Physical Characteristics
Form Factor: Ceiling Mountable
Height: 2.1"
Width: 8.7"
Depth: 8.7"
Weight (Approximate): 2.30 lb
AIR-CAP2602I-C-K9 Miscellaneous
Certifications & Standards: •FCC Bulletin OET-65C
•RSS-102
•UL 60950-1
•CAN/CSA-C22.2 No. 60950-1
•UL 2043
•IEC 60950-1
•EN 60950-1
•EN 50155
AIR-CAP2602I-C-K9 Radio Approvals:
•FCC Part 15.247, 15.407
•RSS-210 (Canada)
•EN 300.328, EN 301.893 (Europe)
•ARIB-STD 66 (Japan)
•ARIB-STD T71 (Japan)
•EMI and susceptibility (Class B)
•FCC Part 15.107 and 15.109
•ICES-003 (Canada)
•VCCI (Japan)
•EN 301.489-1 and -17 (Europe)
•EN 60601-1-2
AIR-CAP2602I-C-K9 IEEE Standards:
•IEEE 802.11a
•IEEE 802.11b
•IEEE 802.11g
•IEEE 802.11n
•IEEE 802.11h
•IEEE 802.11d
•IEEE 802.3af
•IEEE 802.3
•IEEE 802.3u
•IEEE 802.3ab
AIR-CAP2602I-C-K9 PRODUCT DETAILS
Device Type Radio access point
Enclosure Type External
Dimensions (WxDxH) 22.1 cm x 22.1 cm x 5.4 cm
Weight 1.04 kg
RAM Installed ( Max ) 256 MB
Flash Memory Installed (Max) 32 MB
Data Link Protocol IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Frequency Band 2.4 GHz, 5 GHz
AIR-CAP2602I-C-K9 General Information
Manufacturer Cisco Systems, Inc
Manufacturer Part Number AIR-CAP2602I-C-K9
Manufacturer Website Address www.cisco.com
Brand Name Cisco
Product Line Aironet
Product Series 2600
Product Model 2602I
Product Name Aironet 2600I Access Point
Marketing Information The new Cisco® Aironet® 2600 Series Access Point delivers the most advanced features in its class - with great performance, functionality, and reliability at a great price. The 802.11n based Aironet 2600 Series includes 3x4 MIMO, with three spatial streams, plus Cisco CleanAir™, ClientLink 2.0™, and VideoStream technologies, to help ensure an interference-free, high-speed wireless application experience. Second only to the Cisco Aironet 3600 Series in performance and features, the Aironet 2600 Series sets the new standard for enterprise wireless technology.
AIR-CAP2602I-C-K9 Technical Information
Wi-Fi Standard IEEE 802.11n
ISM Band Yes
UNII Band Yes
ISM Minimum Frequency 2.41 GHz
ISM Maximum Frequency 2.47 GHz
UNII Minimum Frequency 5.75 GHz
UNII Maximum Frequency 5.83 GHz
Antenna Gain 4 dBi
Antenna Type Omnidirectional Antenna
Wireless Transmission Speed 450 Mbps
AIR-CAP2602I-C-K9 Interfaces/Ports
Ethernet Port Yes
Fast Ethernet Port Yes
Gigabit Ethernet Port Yes
10Gigabit Ethernet Port No
Number of Network (RJ-45) Ports 1
AIR-CAP2602I-C-K9 Physical Characteristics
Form Factor Ceiling-mountable
Height 2.1"
Width 8.7"
Depth 8.7"
Weight (Approximate) 2.30 lb
AIR-CAP2602I-C-K9 Technical InformationWireless LAN Standard:
IEEE 802.11n
ISM Band: Yes
UNII Band: Yes
ISM Minimum Frequency: 2.41 GHz
ISM Maximum Frequency: 2.47 GHz
UNII Minimum Frequency: 5.75 GHz
UNII Maximum Frequency: 5.83 GHz
Antenna Gain: 4 dBi
Antenna Type: Omnidirectional Antenna
Wireless Transmission Speed: 450 Mbps
Wireless Security: EAP-MSCHAPv2
IEEE 802.1X
IEEE 802.11i
MSCHAPv2
EAP-TTLS
EAP-TLS
WPA2
PEAP
WPA
TKIP
AES
AIR-CAP2602I-C-K9 Interfaces/PortsEthernet Port: Yes
Fast Ethernet Port: Yes
Gigabit Ethernet Port: Yes
10Gigabit Ethernet Port: No
Number of Network (RJ-45) Ports: 1
Network (RJ-11): No
PoE (RJ-45) Port: No
VGA: No
HDMI: No
Audio Line Out: No
Serial Port: No
USB: No
Powerline: No
Management Port: Yes
