AIR-AP342E2RUS

Manufacturer Part#: Cisco AIR-AP342E2RUS
AIR-AP342E2RUS Cisco Wireless Access Point (AP)

AIR-AP342E2RUS Wireless Access Point - 11Mbps - 1 x

The Aironet 342 Access Point performs functions similar to a hub in a wired network. In addition, they add the vital, price/performance benefits of security, management features, and mobility services. For example, the innovative roaming functionality provided by Aironet access point enables users equipped with wireless client adapters to freely move throughout a facility while maintaining seamless, uninterrupted access to the network. It features easy integration to a wired network backbone, flexible configuration, management capabilities, and a wide range of product configurations.

Cisco AIR-AP342E2RUS General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Line: Aironet
Product Series: 340
Product Model: 342
Product Name: Aironet 342 Access Point
Product Type: Wireless Access Point

Cisco AIR-AP342E2RUS Technical Information:
Wi-Fi Standard: IEEE 802.11b
ISM Band: Yes
ISM Minimum Frequency: 2.4 GHz
ISM Maximum Frequency: 2.4834 GHz
Antenna Connector: Dual RP-TNC Connector
Indoor Antenna Range: 300 ft
Outdoor Antenna Range: 1500 ft
Channels: 3 Channel Non-overlapping
Channels: 11 Channel Operating IEEE 802.11b USA & Canada
Wireless Transmission Speed: 11 Mbps
Transmission Speed Details: 1Mbps IEEE 802.11b
Transmission Speed Details: 11Mbps Auto-fallback IEEE 802.11b
Modulation:
Direct Sequence Spread Spectrum (DSSS)
CCK: 5.5 and 11 Mbps
DQPSK: 2 Mbps
DBPSK: 1 Mbps
Direct Sequence Spread Spectrum (DSSS)
CCK: 5.5 and 11 Mbps
DQPSK: 2 Mbps
DBPSK: 1 Mbps

Cisco AIR-AP342E2RUS Interfaces/Ports:
Number of Ports: 1
Fast Ethernet Port: Yes
Interfaces/Ports: 1 x DB-9 Console Management
Interfaces/Ports: 1 x RJ-45 10/100Base-TX LAN

Cisco AIR-AP342E2RUS Management & Protocols:
Management:
DHCP
BOOTP
HTTP
Telnet
FTP
SNMP Compliance: MIB I, MIB II
DHCP
BOOTP
HTTP
Telnet
FTP
SNMP Compliance: MIB I, MIB II

Cisco AIR-AP342E2RUS Power Description:
Input Voltage: 110 V AC
Input Voltage Range: 110V AC to 120V AC
Power Source: Power Supply

Cisco AIR-AP342E2RUS Physical Characteristics:
Dimensions: 6.3 Height x 4.72 Width x 1.45 Depth
Weight: 12.3 oz
