Product Description
Waterproof fiber optic patch cord
- Steel tape armoured.
- Better environment flexibility,
- Comprised with optical connector and endurable waterproof pigtail.
- Easily and reliable installment, long life, good toughness
- Waterproof, Strong Tensibility, Corrosion resistance and suitable for outdoor harsh environment
Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
Ferrule End-face: PC, UPC, APC
Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
Cable Quantity: Duplex, Simplex, 6cores, 12cores. etc
Cable Diameter: Ф3.0mm, Ф2.0mm, Ф0.9mm
Cable Length: 1, 2, 3 meter or customized
Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum
- Steel tape armoured.
- Better environment flexibility,
- Comprised with optical connector and endurable waterproof pigtail.
- Easily and reliable installment, long life, good toughness
- Waterproof, Strong Tensibility, Corrosion resistance and suitable for outdoor harsh environment
Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
Ferrule End-face: PC, UPC, APC
Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
Cable Quantity: Duplex, Simplex, 6cores, 12cores. etc
Cable Diameter: Ф3.0mm, Ф2.0mm, Ф0.9mm
Cable Length: 1, 2, 3 meter or customized
Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum
|
Cable type
|
Cable Diameter
|
Cable weight
|
Bending Radius(MM)
|
|
Tension Strength(N)
|
|
Crush Resistance(N/100MM)
|
|
|
(core q'ty)
|
(MM)
|
(KG/KM)
|
Static
|
Dynamic
|
Short term
|
Long term
|
Short term
|
Long term
|
|
2
|
8.0±0.5
|
65
|
20D
|
10D
|
1500
|
600
|
1000
|
300
|
|
4
|
8.0±0.5
|
68
|
20D
|
10D
|
1500
|
600
|
1000
|
300
|
|
6
|
9.3±0.5
|
85
|
20D
|
10D
|
1500
|
600
|
1000
|
300
|
|
8
|
10.5±0.5
|
110
|
20D
|
10D
|
1500
|
600
|
1000
|
300
|
|
12
|
13.2±0.5
|
170
|
20D
|
10D
|
1500
|
600
|
1000
|
300
|
