WS-X4606-X2-E

Manufacturer Part#:  Cisco WS-X4606-X2-E
WS-X4606-X2-E Cisco Line Card E-Series - switch - 6 port
Cisco WS-X4606-X2-E Support through Centrics Support Services

The Cisco Catalyst 4500 6-port E-Series WS-X4606-X2-E 10 Gigabit Ethernet line card can be deployed for high-performance 10 Gigabit Ethernet aggregation in the campus, in small to medium networks as a core switch, or for high-performance wiring closets where additional 10 Gigabit Ethernet uplinks are required. The Cisco Catalyst 4500 E-Series 6-port 10 Gigabit Ethernet line card supports standard X2 optics as well as the Cisco TwinGig modules.

The Cisco Catalyst 4500 Series offers two classes of line cards: classic and E-Series. Classic line cards provide 6 gigabits of switching capacity per slot. E-Series line cards increase the per slot switching capacity to 24 gigabits. This increase in per slot switching capacity with the E-Series line cards requires the Cisco Catalyst 4500 E-Series chassis and the Cisco Catalyst 4500 Series Supervisor Engine 6-E. Classic line cards may be deployed in both classic and E-Series chassis with either classic Cisco Catalyst 4500 Series supervisor engines or with the Supervisor Engine 6-E. With the Supervisor Engine 6-E, the classic line cards per slot switching capacity remains at 6 gigabits per slot. However, because of the centralized switching architecture of the Cisco Catalyst 4500, the classic line cards will adopt all of the new Supervisor Engine 6-E features such as eight queues per port, dynamic QoS, and hardware-based IPv6 routing. Please refer to the Supervisor Engine 6-E data sheet for more feature details. Classic line cards and E-Series line cards may be mixed and matched within a Cisco Catalyst 4500 E-Series chassis with no performance degradation: classic line cards will operate at 6 gigabits per slot, and E-Series line cards will operate at 24 gigabits per slot. Table 1 summarizes the chassis and supervisor support for both classic and E-Series line cards.

WS-X4606-X2-E Product Details
Device Type Switch - 6 ports
Enclosure Type Plug-in module
Interfaces 10 Gigabit Ethernet
Ports 6 x X2
Dimensions (WxDxH) 36.2 cm x 27.3 cm x 3 cm
Designed For Catalyst 4503-E, 4506-E, 4507R-E, 4510R-E

WS-X4606-X2-E General Information
Manufacturer Cisco Systems, Inc
Manufacturer Part Number WS-X4606-X2-E=
Manufacturer Website Address www.cisco.com
Brand Name Cisco

WS-X4606-X2-E Product Model X4606-X2-E
Product Name Catalyst X4606-X2-E Gigabit Line Card

WS-X4606-X2-E Catalyst 4500 E-Series 6-Port 10GbE (X2)
Módule Expansão
Quatidade Portas: 48 ports
Dimensões (CxLxA): 36.2 cm x 27.3 cm x 3 cm

WS-X4606-X2-E Marketing Information
The Cisco Catalyst X4606-X2-E is a high-performance next-generation extension to the Cisco Catalyst 4500 Series. The new X4606-X2-E is composed of the Cisco Catalyst 4500 Series Supervisor Engine 6-E with CenterFlex technology, X4606-X2-E line card, is designed for secure, flexible, nonstop communications with superior backward and forward compatibility delivering exceptional investment protection for organizations of all sizes.

Product Type Service Module
WS-X4606-X2-E Catalyst 4500 E-Series 6-Port 10GbE (X2)

WS-X4606-X2-E physical
Width  36.2 cm
Depth  27.3 cm
Height  3 cm
Device Type  Expansion module - 6 ports
Form Factor  Plug-in module
Expansion Slots Total (Free)  6 ( 6 ) x X2

WS-X4606-X2-E Compatible Slots  1 x expansion slot

WS-X4606-X2-E Additional Information
•TwinGig modules must be used in groups of three: ports 1-3 or ports 4-6
•L2-4 Jumbo Frame support (up to 9216 bytes)

WS-X4606-X2-E Connectivity Technology  Wired
Cabling Type  Ethernet 10GBase-X
Data Link Protocol  10 Gigabit Ethernet
Data Transfer Rate  10 Gbps
Features  Jumbo Frames support
Compliant Standards  IEEE 802.3
Compliant Standards  NEBS level 3, CE, FCC Class A certified, CISPR 22 Class A, EN 60950, IEC950, UL 1950, VCCI Class A ITE, CSA 22.2 No. 950, EN55022 Class A, AS/NZS 3548
Min Operating Temperature  0 ÃðC
Max Operating Temperature  40 ÃðC
Humidity Range Operating  10 - 90%

WS-X4606-X2-E Products Status: Stock
Brand Name: CISCO
Model Number: WS-X4606-X2-E
Place of Origin:  The United States

WS-X4606-X2-E Specifications:
cisco WS-X4606-X2-E
Cisco Line Card E Series 6 Port Expansion Module
Catalyst 4500 E-Series 6-Port 10

WS-X4606-X2-E Cisco WS-X4606-X2-E Media & Performance
Data Transfer Rate: 10Gbps Gigabit Ethernet

Cisco WS-X4606-X2-E I/O Expansions
Expansion Slots: 6 x X2 Free
Cisco WS-X4606-X2-E Physical Characteristics
Dimensions: 1.2 Height x 14.3 Width x 10.7 Depth

WS-X4606-X2-E Compatibility:
Cisco Catalyst 4503-E
Cisco Catalyst 4506-E
Cisco Catalyst 4507R-E
Cisco Catalyst 4510R-E
Cisco Catalyst 4503-E
Cisco Catalyst 4506-E
Cisco Catalyst 4507R-E
Cisco Catalyst 4510R-E

Contact Sea Tel International for more information.
