WS-SVC-FWM-1-K9
WS-SVC-FWM-1-K9

WS-SVC-FWM-1-K9

Product ID : Cisco Firewall Service Module
Product Description

Manufacturer Part#: Cisco WS-SVC-FWM-1-K9
WS-SVC-FWM-1-K9 Cisco Firewall Service Module

WS-SVC-FWM-1-K9 - CISCO LINE CARD FIREWALL BLADE FOR CATALYST 6500
Cisco Firewall Service Module security appliance

In stock and ready to ship

The WS-SVC-FWM-1-K9 Firewall Services Module (FWSM) - a high-speed, integrated firewall module that provides the fastest firewall data rates in the industry: 5 GB throughput, 100, 000 CPS, and 1M concurrent connections. Up to four FWSMs can be installed in a single chassis providing scalability to 20 GB per chassis. As part of the world-leading Cisco PIX Firewall family, the FWSM provides large enterprises and service providers with unmatched security, reliability, and performance.


The FWSM leverages Cisco PIX technology and runs the Cisco PIX Operating System (OS), a real-time, hardened, embedded system that eliminates security holes and performance-degrading overhead. At the heart of the system, a protection scheme based on the Adaptive Security Algorithm (ASA) offers stateful connection-oriented firewalling. Using ASA, the FWSM creates a connection table entry for a session flow based on the source and destination addresses, randomized TCP sequence numbers, port numbers, and additional TCP flags. The FWSM controls all inbound and outbound traffic by applying the security policy to these connection table entries.

Cisco WS-SVC-FWM-1-K9 General Information
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: Firewall Services Module
Product Type: Firewall Services Module

Cisco WS-SVC-FWM-1-K9 Interfaces/Ports
Interfaces/Ports Details: Not Applicable

Cisco WS-SVC-FWM-1-K9 Media & Performance
Connectivity Media: Not Applicable
Data Transfer Rate: Not Applicable

Cisco WS-SVC-FWM-1-K9 Management & Protocols
Management:
Secure, Triple Data Encryption Standard (3DES)-encrypted network management access
Secure, Triple Data Encryption Standard (3DES)-encrypted network management access

Protocols: ISL
Protocols: OSPF
Protocols: RIP
Protocols: XDMCP
Protocols: Skinny
Protocols: H.323 v2
Protocols: RAS v2
Protocols: RTSP
Protocols: SIP

Cisco WS-SVC-FWM-1-K9
Memory
Memory: 128MB CompactFlash (CF) Card Installed
Memory: 1GB RAM Installed

Cisco WS-SVC-FWM-1-K9 Power Description
Power Consumption: 215 W

Cisco WS-SVC-FWM-1-K9 Environmental Conditions
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Temperature: -40 degrees F (-40.0 degrees C) to 167 degrees F (75.0 degrees C) Non-operating
Humidity: 10% to 90% Non-condensing

Cisco WS-SVC-FWM-1-K9 Physical Characteristics
Dimensions: 1.18 Height x 15.51 Width x 16.34 Depth
Shipping Dimensions: 7.5 Height x 21.75 Width x 22.5 Depth
Weight: 3 lb to 5 lb
