Product Description

Manufacturer Part#: Cisco WS-C4506-S4-AP50
WS-C4506-S4-AP50 Cisco Catalyst 4500 Series switch

WS-C4506-S4-AP50 - Switch Chassis - 1 x Supervisor Engine, 5 x Switching Module

 Catalyst 4506-S4-AP50 switch is a six-slot switch designed for high-performance, high-density wiring closet applications. The Catalyst 4506 switch supports the Supervisor Engine II, II+, II+10GE, III, IV, V, and V-10GE. The supervisor engine has a nonblocking, full-duplex, switching fabric that provides connections between the supervisor engine and the switching modules. The Gigabit Ethernet ports can be configured with any combination of copper 1000BASE-T, shortwave SX, LX/LH, and ZX interfaces, or CWDM and DWDM GBICs.

Cisco WS-C4506-S4-AP50 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: 4500
Product Model: 4506
Product Name: Catalyst 4506 Switch Chassis
Product Type: Switch Chassis

Cisco WS-C4506-S4-AP50 Interfaces/Ports:
Interfaces/Ports: LAN

Cisco WS-C4506-S4-AP50 Media & Performance:
Performance: 48Mpps Forwarding/Filtering Rate
Performance: 64Gbps Bandwidth

Cisco WS-C4506-S4-AP50 I/O Expansions:
Number of Expansion Slots: 6
Expansion Slots: (5 Total /4 Free /1 Populated) Switching Module
Expansion Slots: (1 Total /1 Populated) Supervisor Engine
Modules: 1 x WS-X4515 Supervisor Engine
Modules: 1 x WS-X4306-GB Switching Module

Cisco WS-C4506-S4-AP50 Network & Communication:
Layer Support: 2 to 4

Cisco WS-C4506-S4-AP50 Management & Protocols:
Manageable: Yes
Management:


•RMON
•Telnet
•SNMP v1,2c
•CLI
•VLAN
•CiscoView graphical device management


Cisco WS-C4506-S4-AP50 Software:
Operating System:
Cisco IOS

Cisco WS-C4506-S4-AP50 Power Description:
Power Over Ethernet: Yes
Input Voltage: 110V AC
Input Voltage: 220V AC
Power Source: Power Supply
Redundant Power Supply: Yes

Cisco WS-C4506-S4-AP50 Physical Characteristics:
Form Factor: Rack-mountable
Dimensions: 17.38 Height x 17.31 Width x 12.5 Depth
Weight: 100lb
Weight: 40.5lb
