The Cisco Catalyst 3560 series is a line of fixed-configuration, enterprise-class switches that include IEEE 802.3af and Cisco pre-standard Power over Ethernet (PoE) functionality in Fast Ethernet and Gigabit Ethernet configurations. The Cisco Catalyst 3560 is an ideal access layer switch for small enterprise LAN access or branch-office environments, combining both 10/100/1000 and PoE configurations for maximum productivity and investment protection while enabling the deployment of applications such as IP telephony, wireless access, video surveillance, building management systems, and remote video kiosks. Customers can deploy network-wide intelligent services - such as advanced quality of service (QoS), rate limiting, access control lists (ACLs), multicast management, and high-performance IP routing - while maintaining the simplicity of traditional LAN switching.
The Cisco WS-C3560-12PC-S Catalyst Switch is an ideal Switch for small enterprise LAN access or branch-office environments, combining 12 ports of 10/100 and PoE for maximum productivity and investment protection while enabling the deployment of new applications such as IP telephony, wireless access, video surveillance, building management systems, and remote video kiosks. Users can deploy networkwide intelligent services-such as advanced quality of service (QoS), rate limiting, access control lists (ACLs), multicast management, and high-performance IP routing-while maintaining the simplicity of traditional LAN switching. The included Cisco Network Assistant is a centralised management application that simplifies the administration tasks for Cisco switches, routers, and wireless access points.
WS-C3560-12PC-S Part Code: WS-C3560-12PC-S
•Manufacturer: Cisco
•Device Type: Switch - 12 ports - L3 - Managed
•Enclosure Type: Desktop 1U
•Interfaces: Fast Ethernet
•Ports: 12 x 10/100 (PoE) + 1 x combo Gigabit SFP
WS-C3560-12PC-S Product Details
Device Type Switch - 12 ports - L3 - Managed
Enclosure Type Desktop 1U
Interfaces Fast Ethernet
Ports 12 x 10/100 (PoE) + 1 x combo Gigabit SFP
Power Over Ethernet (PoE) PoE
MAC Address Table Size 12K entries
Routing Protocol RIP-1, RIP-2, HSRP, static IP routing, policy-based routing (PBR), RIPng
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, FTP, TFTP, SSH-2
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
Power AC 120/230 V ( 50/60 Hz )
WS-C3560-12PC-S Dimensions (WxDxH) 27 cm x 23 cm x 4.4 cm
Weight 2.3 kg
Manufacturer Warranty Limited lifetime warranty
WS-C3560-12PC-S Key Features:
•Twelve (12) 10/100 Fast Ethernet RJ45 ports with Auto-MDIX negotiation
•One (1) Dual-Purpose Gigabit & SFP port for high speed uplinks and for network expansion.
•1202.3af and Cisco prestandard PoE support comes with automatic discovery to detect a Cisco prestandard or 1202.3af endpoint and provide the necessary power up to 15W per port (124W total) without any user configuration.
•Wide range of security features to protect important information, keep unauthorised people off the network, guard privacy, and maintain uninterrupted operation.
•Automatic QoS (Auto QoS) simplifies QoS configuration in voice-over-IP (VoIP) networks by issuing interface and global switch commands to detect Cisco IP phones, classify traffic, and enable egress queue configuration.
•Cisco EnergyWise for greenhouse gas emissions and operational cost optimization by measuring, reporting, and reducing energy consumption across the entire corporate infrastructure, well beyond the scope of IT.
•Includes Cisco LAN Base iOS, Upgrading the Cisco IOS Software on Cisco Catalyst switches is a simple matter of pointing and clicking, with one-click upgrades.
•The IP Base license offers advanced QoS, rate limiting, ACLs, and basic static and Routing Information Protocol (RIP) routing functions
•Limited lifetime hardware warranty, including next-business-day replacement with 90-day service and support
WS-C3560-12PC-S Cisco WS-C3560-12PC-S — Catalyst 3560 Compact 12 10/100 PoE + 1 T/SFP; IP Base Image
•Name: WS-C3560-12PC-S
•Product Series: 3560
•Number of Ports: 13
•Dimensions: 1.73" Height x 10.60" Width x 9.10" Depth
•Standard Memory: 128MB DRAM
•Memory Technology: DRAM
WS-C3560-12PC-S Features:
•Ports : Twelve (12) RJ-45 10/100Base-TX Fast Ethernet 802.3af PoE
•Uplink Ports : One (1) dual-purpose 10/100/1000Base-T and SFP port
•Management ports : One (1) RJ-45 serial console
•Management protocols : SNMP and CLI
•GBIC Modules : Not included
•Power Supply : AC or DC (RPS port available)
•Flash Size : 32MB
•DRAM : 128MB
•Form Factor : 1U Desktop
•Model Number : WS-C3560-12PC-S
•Part Number : WS-C3560-12PC-S
•Condition : Used, tested, working, and sold with warranty
WS-C3560-12PC-S General Information
Manufacturer Part Number: WS-C3560-12PC-S
Device Type: Switch - 12 ports - L3 - managed
Enclosure Type: Desktop - 1U
Ports: 12 x 10/100 + 1 x combo Gigabit SFP
MAC Address Table Size: 12K entries
Power Over Ethernet (PoE): PoE
Routing Protocol: RIP-1, RIP-2, HSRP, static IP routing, policy-based routing (PBR), RIPng
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, FTP, TFTP, SSH-2
WS-C3560-12PC-S Features:
Auto-sensing per device, IP-routing, DHCP support, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+)
WS-C3560-12PC-S RAM: 128 MB
Flash Memory: 32 MB flash
Status Indicators: Port status, link activity, port transmission speed, port duplex mode, power, system
WS-C3560-12PC-S Product Line: Cisco Catalyst
Model: 3560-12PC
Compatibility: PC
Manufacturer: Cisco Systems
Packaged Quantity: 1
Expansion / Connectivity
Interfaces: 12 x 10Base-T/100Base-TX - RJ-45 - PoE ¦ 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x console - RJ-45 - management ¦ 1 x SFP (mini-GBIC)
WS-C3560-12PC-S Physical Characteristics
Width: 10.6 in
Depth: 9.1 in
Height: 1.7 in
Weight: 5.1 lbs
WS-C3560-12PC-S Power
Power Device: Power supply - internal
Voltage Required: AC 120/230 V ( 50/60 Hz )
WS-C3560-12PC-S Compliant Standards:
FCC Class A certified, UL, TUV GS, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, UL 60950 Third Edition, CB, AS/NZ 3548 Class A, FCC Part 15, CSA C22.2 No. 60950-00, MIC
Subcategory: Network hubs and switches
Subtype: Fast Ethernet
