Product Description
Manufacturer Part#: Cisco VG224
VG224 Cisco VoIP Gateway
VG224 - 24-Port Voice over IP Analog Phone Gateway 24 Port Voice over IP analog phone gateway
Cisco VG224 is a Cisco IOS Software-based high-density 24-port gateway for analog phones, fax machines, modems, and speaker phones within an enterprise voice system based on Cisco Unified CallManager. Having these devices tightly integrated with the IP-based phone system is advantageous for increased manageability, scalability, and cost-effectiveness. Commercial businesses can also use the Cisco VG224 with Cisco Unified CallManager Express to effectively augment an integrated services router (ISR) environment. Either topology environment will support business needs for a high concentration of analog voice ports for modem calls, fax calls, and analog supplementary services. The Cisco VG224 offers Cisco IOS Software manageability with 24 analog phone lines to be used as extensions to the Cisco Unified CallManager or Cisco Unified CallManager Express system in a very compact 19-inch rack-mount chassis.
Cisco VG224 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: VG200
Product Model: VG224
Product Name: VG224 24-Port Voice over IP Analog Phone Gateway
Product Type: VoIP Gateway
Cisco VG224 Technical Information:
Voice Codec: G.729a
Voice Codec: G.711
Cisco VG224 I/O Expansions:
Expansion Slots: (1 Total) CompactFlash (CF) Card
Cisco VG224 Interfaces/Ports:
Interfaces/Ports: 2 x RJ-45 10/100Base-TX LAN
Interfaces/Ports: 1 x RJ-21 FXS
Interfaces/Ports: 1 x RJ-45 Console Management
Interfaces/Ports: 1 x RJ-45 Auxiliary Management
Cisco VG224 Media & Performance:
Connectivity Media: Twisted Pair 10/100Base-TX
Data Transfer Rate: Up to 119.2Kbps Console per Port
Data Transfer Rate: 10Mbps Ethernet
Data Transfer Rate: Up to 119.2Kbps Auxiliary per Port
Data Transfer Rate: 100Mbps Fast Ethernet
Cisco VG224 Management & Protocols:
Management:
CLI
Telnet
SNMPv3
HTTP server
IEEE 802.1p QoS
Cisco Unified CallManager 3.3.3 SR2 or higher version
Cisco Unified CallManager Express 4.3.2 or higher version
CLI
Telnet
SNMPv3
HTTP server
IEEE 802.1p QoS
Cisco Unified CallManager 3.3.3 SR2 or higher version
Cisco Unified CallManager Express 4.3.2 or higher version
VG224 Security Features:
RADIUS and TACACS+ for Telnet and authorization
Cisco VG224 Power Description:
Input Voltage: 12 V DC Device
Input Voltage: 100 V AC to 240 V AC Power Supply
Cisco VG224 Physical Characteristics:
Form Factor: 19 Rack-mountable
Form Factor: Wall-mountable
Form Factor: Desktop
Dimensions: 1.75 Height x 17.5 Width x 13.5 Depth
Shipping Dimensions: 10 Height x 17 Width x 21 Depth
Weight: 11 lb Maximum
Shipping Weight: 17 lb
VG224 Cisco VoIP Gateway
VG224 - 24-Port Voice over IP Analog Phone Gateway 24 Port Voice over IP analog phone gateway
Cisco VG224 is a Cisco IOS Software-based high-density 24-port gateway for analog phones, fax machines, modems, and speaker phones within an enterprise voice system based on Cisco Unified CallManager. Having these devices tightly integrated with the IP-based phone system is advantageous for increased manageability, scalability, and cost-effectiveness. Commercial businesses can also use the Cisco VG224 with Cisco Unified CallManager Express to effectively augment an integrated services router (ISR) environment. Either topology environment will support business needs for a high concentration of analog voice ports for modem calls, fax calls, and analog supplementary services. The Cisco VG224 offers Cisco IOS Software manageability with 24 analog phone lines to be used as extensions to the Cisco Unified CallManager or Cisco Unified CallManager Express system in a very compact 19-inch rack-mount chassis.
Cisco VG224 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: VG200
Product Model: VG224
Product Name: VG224 24-Port Voice over IP Analog Phone Gateway
Product Type: VoIP Gateway
Cisco VG224 Technical Information:
Voice Codec: G.729a
Voice Codec: G.711
Cisco VG224 I/O Expansions:
Expansion Slots: (1 Total) CompactFlash (CF) Card
Cisco VG224 Interfaces/Ports:
Interfaces/Ports: 2 x RJ-45 10/100Base-TX LAN
Interfaces/Ports: 1 x RJ-21 FXS
Interfaces/Ports: 1 x RJ-45 Console Management
Interfaces/Ports: 1 x RJ-45 Auxiliary Management
Cisco VG224 Media & Performance:
Connectivity Media: Twisted Pair 10/100Base-TX
Data Transfer Rate: Up to 119.2Kbps Console per Port
Data Transfer Rate: 10Mbps Ethernet
Data Transfer Rate: Up to 119.2Kbps Auxiliary per Port
Data Transfer Rate: 100Mbps Fast Ethernet
Cisco VG224 Management & Protocols:
Management:
CLI
Telnet
SNMPv3
HTTP server
IEEE 802.1p QoS
Cisco Unified CallManager 3.3.3 SR2 or higher version
Cisco Unified CallManager Express 4.3.2 or higher version
CLI
Telnet
SNMPv3
HTTP server
IEEE 802.1p QoS
Cisco Unified CallManager 3.3.3 SR2 or higher version
Cisco Unified CallManager Express 4.3.2 or higher version
VG224 Security Features:
RADIUS and TACACS+ for Telnet and authorization
Cisco VG224 Power Description:
Input Voltage: 12 V DC Device
Input Voltage: 100 V AC to 240 V AC Power Supply
Cisco VG224 Physical Characteristics:
Form Factor: 19 Rack-mountable
Form Factor: Wall-mountable
Form Factor: Desktop
Dimensions: 1.75 Height x 17.5 Width x 13.5 Depth
Shipping Dimensions: 10 Height x 17 Width x 21 Depth
Weight: 11 lb Maximum
Shipping Weight: 17 lb
