MTRJ Duplex Single mode Fiber Optic Patch Cord
MTRJ Duplex Single mode Fiber Optic Patch Cord

MTRJ Duplex Single mode Fiber Optic Patch Cord

Product Description
The MTRJ is with duplex plastic ferrule and compliant to TIA/EIA 568-A.  this patch cord is duplex type, with 50/125 multimode or 62.5/125 multimode optical fiber.

Types:
- Connector: ST, FC, SC, LC, MU, D4, MTRJ, SMA(905/906), FDDI, MPO, E2000, MU. VF45, etc.
- Core: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
- Polishing:PC, UPC and APC.
- Cable Quantity: Duplex, Simplex, 6cores, 12cores. etc
- Cable Diameter: Ф3.0mm, Ф2.0mm, Ф0.9mm
- Cable Length: 1, 2, 3, 10 meters or customized
- Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum

Application:
- ATM
- Gigabit Ethernet
- CATV, video
- Multimedia applications

Specifications:

Items

Single mode

Multimode

Insertion Loss

≤0.30dB

≤0.3dB

Return Loss

≥50 dB (PC)
≥65 dB (APC)



Repeatability

≤0.1



Durability

≤0.2 dB typical change, 1000 matings



Interchangeability

≤0.2dB



Tensile strength

>10kg



Operating Temperature

-40 to + 85°C

-40 to + 85°C
