LD-417G

Manufacturer Part#: Cisco LD-417G
LD-417G Server Load Balancers

LD-417G - Cisco Local Director Series offers a high-availability, integrated hardware and software solution that intelligently balances the load of user traffic across multiple TCP/IP application servers. Cisco Local Director tracks network sessions and server load conditions in real time, directing each session to the most appropriate server. All physical servers appear as one virtual server, requiring only a single IP address and a single URL for an entire server farm.

Cisco LD-417G Media & Performance:
Connectivity Media: Twisted Pair
Data Transfer Rate: 10Mbps Ethernet
Data Transfer Rate: 100Mbps Fast Ethernet
Data Transfer Rate: 1Gbps Gigabit Ethernet
Performance: 80 Mbps Throughput

Cisco LD-417G Management & Protocols:
Management:
HTTP
Telnet
HTTP
Telnet

Cisco LD-417G Memory:
Standard Memory: 512MB RAM
Standard Memory: 16MB Flash

Cisco LD-417G Power Description:
Input Voltage: 110V AC

Cisco LD-417G General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: Cisco Local Director Load Balancer
Product Type: Server Load Balancer

Cisco LD-417G Technical Information:
Load Balance Applications: Web

Cisco LD-417G Interfaces/Ports:
Interfaces/Ports: 2 x RJ-45 10/100Base-TX
Interfaces/Ports: 2 x SC Duplex 1000Base-SX
Interfaces/Ports: 1 x RJ-45 Console Management
Interfaces/Ports: 1 x DB-15 Failover

Cisco LD-417G Media & Performance:
Connectivity Media: 62.5/125 micron Multi-mode Fiber
Connectivity Media: 50/125 micron Multi-mode Fiber

Cisco LD-417G Power Description:
Input Voltage: 220V AC
Input Voltage Range: 100 V AC to 240 V AC

Cisco LD-417G Environmental Conditions:
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Temperature: -13 degrees F (-25.0 degrees C) to 158 degrees F (70.0 degrees C) Storage
Humidity: 5 to 95% Operating
Altitude: 6500 ft Maximum Operating

Cisco LD-417G Physical Characteristics:
Form Factor: 1U 19 Rack-mountable
Dimensions: 1.72 Height x 17.5 Width x 14.13 Depth
Shipping Dimensions: 8 Height x 25 Width x 28 Depth

Cisco LD-417G Miscellaneous:
•64,000 virtual and real IP addresses
•1,000,000 simultaneous TCP connections
•SSL and cookie sticky
•Hot-standby configuration replication
