CSS-11151-256M-AC

Manufacturer Part#: Cisco CSS-11151-256M-AC
CSS-11151-256M-AC Content Services Switches (CSS)

CSS-11151-256M-AC - CSS 11151, 12 pt FE (TX), 256MB, HD, AC

Cisco CSS 11151 content services switch is a compact, high-performance solution for small-to medium-sized Web sites. Featuring Cisco Web Network Services (Web NS) software, the Cisco CSS 11151 enables Web and application service providers, Web content providers, and enterprises engaged in e-commerce to build global Web networks optimized for e-commerce transactions and Web content delivery. With its patented content switching technology, the Cisco CSS 11151 gives businesses maximum control in ensuring availability of their Web sites, securing Web site resources without compromising performance, and allocating Web site resources efficiently.

Running on the Cisco CSS 11151, Cisco Web NS software knows who the user is, what the user wants to do, and how best to service the user's request within a global Web infrastructure. The Cisco CSS 11151 supports wire-speed flow forwarding between a client and a Web server, based on the requested content's full URL, as well as user cookie and extensive resource verification information

Cisco CSS-11151-256M-AC Management & Protocols:
Security Features:

•Secure socket layer (SSL) session ID
•Wire-speed, per-flow filtering of content requests
•Security policies can be implemented based on any combination of source address, destination address, protocol, type, or content URL
•Intelligent flow inspection prevents common denial of service attacks such as SYN floods, ping floods, and smurfs
•Wire-speed network address translation protects server IP addresses
•Firewall security
•Site-level security with wire-speed denial-of-service (DoS) prevention

Cisco CSS-11151-256M-AC Processor & Chipset:
Processor: 1 x RISC

Cisco CSS-11151-256M-AC Memory:
Standard Memory: 256MB

Cisco CSS-11151-256M-AC Storage:
Storage: Hard Disk

Cisco CSS-11151-256M-AC Controls/Indicators:
Status Indicators:

•Link activity
•Port transmission speed
•Port duplex mode
•Power

Cisco CSS-11151-256M-AC Power Description:
Input Voltage: 220V AC
Input Voltage: 110V AC
Input Current: 3.1 A Maximum
Frequency: 50 Hz or 60 Hz
Power Consumption: 310 W Maximum
Power Source: Power Supply

Cisco CSS-11151-256M-AC Environmental Conditions:
Temperature: -4 degrees F (-20.0 degrees C) to 149 degrees F (65.0 degrees C) Storage
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Humidity: 10% to 95% Non-condensing Relative Humidity Operating

Cisco CSS-11151-256M-AC Physical Characteristics:
Dimensions: 2.62 Height x 17 Width x 15 Depth
Shipping Dimensions: 9.5 Height x 24.75 Width x 22 Depth
Weight: 16.1lb
Shipping Weight: 23.1 lb

Cisco CSS-11151-256M-AC Miscellaneous:
Certifications & Standards:

•IEEE 802.3
•IEEE 802.3U

Safety:
•UL 1950
•CSA 950
•EN60950
•GS Mark

EMC:
•FCC Part 15 Class A
•EN55022 Class A
•EN 50082-1
•VCCI Class 1

Factory approvals:
•UL
•TUV
•BABT 340

Cisco CSS-11151-256M-AC General Information
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: CSS 11000
Product Name: 11151 Content Switch
Product Type: Content Switch

Cisco CSS-11151-256M-AC Interfaces/Ports
Number of Ports: 12
Fast Ethernet Port: Yes
Interfaces/Ports: 12 x RJ-45 10/100Base-TX LAN
Interfaces/Ports: 1 x RJ-45 Serial Management
Interfaces/Ports: 1 x RJ-45 10/100Base-TX Management
Interfaces/Ports: 1 x RJ-45 Console Management

Cisco CSS-11151-256M-AC Media & Performance:
Connectivity Media: Twisted Pair
Performance: 5Gbps Bandwidth

Cisco CSS-11151-256M-AC I/O Expansions:
Modules: Not Applicable

Cisco CSS-11151-256M-AC Network & Communication:
Address Table: Not Applicable

Cisco CSS-11151-256M-AC Management & Protocols:
Manageable: Yes
Management:

•Cisco Web NS Software
•Powerful command line interface (CLI)
•Telnet
•A graphical user interface (GUI)
•Simple Network Management Protocol (SNMP)
•Remote monitoring (RMON)
•Log files

Protocols: TCP/IP
Protocols: LDAP
Protocols: FTP

Cisco CSS-11151-256M-AC Miscellaneous:
•Slot configuration: Fixed
•Delivers up to 400 percent improvement in Web cache efficiency for transparent, proxy, and reverse proxy configurations
