CSS-11051-AC

Manufacturer Part#: Cisco CSS-11051-AC
CSS-11051-AC  Content Services Switches (CSS)

CSS-11051-AC CSS 11051, 8 pt FE (TX), 128MB, HD, AC

Cisco CSS 11050 content services switch is a compact, high-performance solution for small Web sites and points of presence (PoPs). Featuring Cisco Web Network Services (Web NS) software, the Cisco CSS 11050 enables Web and application service providers, Web content providers, and enterprises engaged in e-commerce to build global Web networks optimized for e-commerce transactions and Web content delivery. With its patented content switching technology, the Cisco CSS 11050 gives businesses maximum control in ensuring availability of their Web sites, securing Web site resources without compromising performance and allocating Web site resources efficiently.

Cisco CSS-11051-AC Physical Characteristics:
Shipping Dimensions: 9.5 Height x 22 Width x 22 Depth
Shipping Weight: 25 lb

Cisco CSS-11051-AC General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: CSS 11000
Product Name: 11051 Content Switch
Product Type: Content Switch

Cisco CSS-11051-AC Interfaces/Ports:
Number of Ports: 8
Fast Ethernet Port: Yes
Interfaces/Ports: 8 x RJ-45 10/100Base-TX LAN

Cisco CSS-11051-AC Media & Performance:
Connectivity Media: Cable Twisted Pair
Performance: 5Gbps Switching Fabric

Cisco CSS-11051-AC Management & Protocols:
Manageable: Yes

Cisco CSS-11051-AC Environmental Conditions:
Temperature: -4 degrees F (-20.0 degrees C) to 149 degrees F (65.0 degrees C) Storage
Humidity: 10% to 95% Non-condensing Relative Humidity

Cisco CSS-11051-AC Physical Characteristics:
Dimensions: 2.62 Height x 17 Width x 15 Depth

Cisco CSS-11051-AC Management & Protocols:
Management: System management capabilities include a powerful command line interface (CLI), a graphical user interface (GUI), and support for Simple Network Management Protocol (SNMP), remote monitoring (RMON), and log files. Effective management tools reduce the ongoing cost of operating a business-critical Web site.
Protocols: TCP/IP
Protocols: FTP
Protocols: HTTP

Cisco CSS-11051-AC Processor & Chipset:
Processor: RISC

Cisco CSS-11051-AC Memory:
Standard Memory: 128MB

Cisco CSS-11051-AC Power Description:
Input Voltage: 110V AC
Input Voltage: 220V AC
Input Voltage Range: 100V AC to 240V AC
Input Current: 3.1A
Frequency: 50 Hz to 60 Hz
Power Consumption: 310 W

Cisco CSS-11051-AC Environmental Conditions:
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating

Cisco CSS-11051-AC Miscellaneous:
Additional Information:
Provides high-speed Web content delivery by selecting the best site and server based on full URL, cookie, and resource availability information
Offers site-level security with wire-speed denial-of-service (DoS) prevention; firewall load-balancing provides scalable security for back-end data-bases and applications
Delivers up to 400 percent improvement in Web cache efficiency for transparent, proxy, and reverse proxy configurations
Provides eight full-duplex fast Ethernet ports
Supports all TCP- and UDP-based Web protocols, wire-speed network address translation (NAT), and integrated IP routing
Optimizes both content requests and delivery for HTTP, passive File Transfer Protocol (FTP), and streaming media protocols
Enables advanced service level agreements (SLAs), and a variety of new fee-based services
Provides high-speed Web content delivery by selecting the best site and server based on full URL, cookie, and resource availability information
Offers site-level security with wire-speed denial-of-service (DoS) prevention; firewall load-balancing provides scalable security for back-end data-bases and applications
Delivers up to 400 percent improvement in Web cache efficiency for transparent, proxy, and reverse proxy configurations
Provides eight full-duplex fast Ethernet ports
Supports all TCP- and UDP-based Web protocols, wire-speed network address translation (NAT), and integrated IP routing
Optimizes both content requests and delivery for HTTP, passive File Transfer Protocol (FTP), and streaming media protocols
Enables advanced service level agreements (SLAs), and a variety of new fee-based services

Certifications & Standards: Safety:
•UL 1950
•CSA 950
•EN60950
•GS Mark

EMC:
•FCC Part 15 Class A
•EN55022 Class A
•EN 50082-1
•VCCI Class 1

Factory approvals:
•UL
•TUV
•BABT 340
