Product ID : Cisco 3700 Series Multiservice Access Router
Product Description
Manufacturer Part#: Cisco CISCO3745-V-CCME
CISCO3745-V-CCME
Cisco 3700 Series Multiservice Access Router

CISCO3745-V-CCME
- Router - 3 x WIC, 4 x Network Module - 2 x 10/100Base-TX LAN

Sea Tel International Co., Limited CISCO 3700 Series Router
CISCO3725-DC-U C3725-VPN/K9 3725MBUNDLE-30DM-U CISCO3725
CISCO3745-V-CCME-A C3725-VPN-IDS/K9 3725MBUNDLE-30DM-B CISCO3745
CISCO3745-V-CCME C3725-VPN-CE/K9 3725MBUNDLE-4B-S/T CISCO3725-V-CCME-A
C3745-VPN/K9 3725MBUNDLE-8B-S/T 3725MBUNDLE-24DM CISCO3725-V-CCME

Cisco 3700 Multiservice Access Routers are based on the same modular concepts as the Cisco 3600 Series but enable dramatically higher levels of performance and service integration for the branch office.

Cisco CISCO3745-V-CCME General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: 3700
Product Name: 3745 Multiservice Access Router
Product Type: Router

Cisco CISCO3745-V-CCME
Interfaces/Ports:
Number of Ports: 2
Fast Ethernet Port: Yes
Interfaces/Ports: 2 x RJ-45 10/100Base-TX LAN
Interfaces/Ports: 1 x RJ-45 Console Management
Interfaces/Ports: 1 x RJ-45 Auxiliary Management

Cisco CISCO3745-V-CCME Media & Performance
Connectivity Media: Category 5 UTP 10/100Base-TX
Distance Support: 328 ft UTP
Forwarding/Filtering Rate: 225Kpps

Cisco CISCO3745-V-CCME I/O Expansions:
Number of Expansion Slots: 11
Expansion Slots: (3 Total) WIC
Expansion Slots: (4 Total) Network Module
Expansion Slots: (2 Total) AIM
Expansion Slots: (2 Total) CompactFlash (CF) Card
Modules: 1 x AIM-ATM-VOICE-30
Modules: 1 x CISCO3745-2FE-I/O IO Controller

Cisco CISCO3745-V-CCME Management & Protocols:
Management:
SNMP
SNMP

Protocols: TCP/IP

Cisco CISCO3745-V-CCME Processor & Chipset:
Processor: 1 PMC-Sierra RM7000A 350MHz RISC

Cisco CISCO3745-V-CCME Memory:
Standard Memory: 256MB
Maximum Memory: 256MB
Memory Technology: DRAM
Flash Memory: 64 MB

Cisco CISCO3745-V-CCME Software:
Operating System:
Cisco 3745 Ser IOS SP SERVICES
Cisco 3745 Ser IOS SP SERVICES

Cisco CISCO3745-V-CCME Power Description:
Input Voltage: 110V AC
Input Voltage: 220V AC
Input Voltage Range: 100V AC to 240V AC
Frequency: 50 Hz or 60 Hz
Power Consumption: 230W Maximum
Power Source: Power Supply
Redundant Power Supply: Yes

Cisco CISCO3745-V-CCME Environmental Conditions:
Temperature: -40 degrees F (-40.0 degrees C) to 185 degrees F (85.0 degrees C) Non-operating
Temperature: 32 degrees F (0.0 degrees C) to 104 degrees F (40.0 degrees C) Operating
Humidity: 5% to 95% Non-condensing Relative Humidity Operating
Altitude: 6500 ft Maximum Operating
Thermal Dissipation: 784.83 BTU/h

Cisco CISCO3745-V-CCME Physical Characteristics:
Compatible Rack Unit: 3U
Form Factor: Rack-mountable
Form Factor: Desktop
Dimensions: 5.25 Height x 17.25 Width x 16 Depth
Shipping Dimensions: 12.5 Height x 22 Width x 22 Depth
Weight: 32 lb
