C9300-48T-E

C9300-48T-E Overview

The Cisco® Catalyst® 9300 Series Switches are Cisco’s lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. C9300-48T-E is 48-port data only, Network Essentials Switch of 9300 series. Catalyst 9300 Series are the next generation of the industry’s most widely deployed switching platform. At 480 Gbps, they are the industry’s highest-density stacking bandwidth solution with the most flexible uplink architecture.Catalyst 9300 48-port data only, Network Essentials

The Cisco Catalyst C9300-48T-E is a high-performance switch that offers advanced features and capabilities for enterprise networks. It is designed to meet the needs of modern business applications and is ideal for deployment in campus networks, branch offices, and data centers.

The C9300-48T-E provides 48 Gigabit Ethernet ports, along with up to four 10 Gigabit Ethernet uplink ports. It supports advanced features such as virtual stacking, network segmentation with VLANs, and Quality of Service (QoS) for enhanced traffic management. It also includes support for Cisco's DNA Center, which allows for streamlined network automation and management.

Specifications for the Cisco Catalyst C9300-48T-E:

• Total number of ports: 48
• Uplink ports: 4 x 10 Gigabit Ethernet
• Switching capacity: 336 Gbps
• Forwarding rate: 250 Mpps
• Power supply: Dual redundant, hot swappable
• Power over Ethernet (PoE): No
• Stackable: Yes (with optional stacking module)
• Dimensions: 1.73 x 17.5 x 17.5 in. (H x W x D)
• Weight: 15.3 lbs

Cisco Catalyst C9300-48T-E is a powerful and versatile switch that can provide reliable and high-performance connectivity for a wide range of enterprise networks.
