C9200L-24P-4X-E Overview

The Cisco Catalyst C9200L-24P-4X-E is a fixed-configuration switch that is part of the Cisco Catalyst 9200 Series. It is designed for small to medium-sized businesses and branch offices, offering advanced security and automation capabilities.

Catalyst C9200L-24P-4X-E switch:

Physical specifications:

Dimensions (H x W x D): 1.73 x 17.5 x 11.62 inches (4.4 x 44.5 x 29.5 cm)

Weight: 9.57 lbs (4.35 kg)

Rack-mountable: Yes, with rack-mount kit (included)

Ports:

24 x 10/100/1000 Ethernet PoE+ ports

4 x 10G SFP+ uplink ports

1 x console port (RJ-45)

1 x USB Type-A port for storage and console

Power over Ethernet:

PoE+ (IEEE 802.3at) with a total power budget of 370W

Supports up to 30W per port

Performance:

Switching capacity: 128 Gbps

Forwarding rate: 95.23 Mpps

MAC address table size: 32,000 entries

Jumbo frame support: Up to 9198 bytes

Layer 2 switching:

VLANs: Up to 4,094

Maximum VLAN IDs: 4K

Spanning Tree Protocol (STP): IEEE 802.1D, IEEE 802.1w, IEEE 802.1s

Link Aggregation Control Protocol (LACP): IEEE 802.3ad

Port mirroring: Supported on all ports

IGMP snooping: IGMP v1/v2/v3

DHCP snooping: Yes

Dynamic ARP inspection (DAI): Yes

Private VLAN: Yes

Voice VLAN: Yes

Layer 3 services:

IPv4 routing: Static, RIPv1, RIPv2

IPv6 routing: Static, RIPng

Access Control Lists (ACLs): Yes

Quality of Service (QoS): Yes

Multicast routing: Protocol Independent Multicast (PIM)

Security:

IEEE 802.1X: Yes

MACsec: Yes

Cisco TrustSec: Yes

DHCP protection: Yes

IP Source Guard: Yes

Dynamic Host Configuration Protocol (DHCP) snooping: Yes

Port security: Yes

Private VLAN: Yes

Management:

Management protocols: SNMP v1/v2c/v3, HTTP, HTTPS, Telnet, SSH

RMON: Yes

Syslog: Yes

Network Time Protocol (NTP): Yes

Simple Network Management Protocol (SNMP): Yes

Cisco Prime Infrastructure: Yes

Cisco DNA Center: Yes

RESTful API: Yes

Environmental specifications:

Operating temperature: 23°F to 113°F (-5°C to 45°C)

Storage temperature: -40°F to 158°F (-40°C to 70°C)

Operating humidity: 10% to 95% noncondensing

Storage humidity: 10% to 95% noncondensing

Certifications:

Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950.1

Electromagnetic compatibility: AS/NZS CISPR 32, EN 55032, CISPR 32, ICES-003, EN61000-3-2, EN61000-3-3, KN24, KN32, EN 300 386, EN 55024, CISPR 24, FCC Part 15

The C9200L-24P-4X-E provides reliable and secure connectivity for a range of business applications. Its PoE+ capability makes it ideal for powering IP phones, cameras, and other devices, while its 10G uplink ports provide high-speed connectivity for uplinking to core switches or servers. Its advanced security features include support for MACsec encryption and Cisco TrustSec, while its automation capabilities allow for simplified network provisioning and management.
