Product ID : C1111-4P
Product Tags : Cisco 1000 Series Router
Product Description

 C1111-4P

ISR 1100 4 Ports Dual GE WAN Ethernet Router

 C1111-4P Overview:
Cisco 1000 Series Integrated Services Routers
The Cisco® 1000 Series Integrated Services Routers (ISR 1000 Series) portfolio has been steadily expanding over the years to provide our customers with the flexibility they need. The ISR 1000 Series combines routing, switching, Wi-Fi, integrated security, and DSL and LTE uplink connectivity options in a single, lightweight, high-performance device. Choose between the traditional Cisco IOS® XE or controller-managed Cisco IOS XE SD-WAN software to deploy your network quickly and reliably on all Cisco ISR 1000 Series routers. With a simple and flexible pay-as-you-grow model, you purchase network capacity only when you need it.

 C1111-4P Key features
●      Industry-leading hardware coupled with feature-rich software combine to make high-performance small-office routers. Up to 800 Mbps IMIX encrypted throughput.
●      Latest-generation LTE uplink technologies, including dual-carrier support and carrier aggregation, with 5G support coming soon.
●      Flexible network management solutions, ranging from local WebUI support to cloud-hosted and on-premises SD-WAN controllers.
●      Wi-Fi 6-capable wireless connectivity embedded into a small-form-factor, fanless, all-in-one device.
●      Advanced security features available on-box, including Enterprise Firewall with Application Awareness, IPS/IDS, Advanced Malware Protection, URL filtering, and Cisco Umbrella® Secure Internet Gateway (SIG) (secure access service edge [SASE]).

Physical Specifications:
Dimensions: 1.7 x 10.6 x 9.4 inches (4.4 x 27 x 23.8 cm)
Weight: 4.41 lbs (2 kg)

Performance Specifications:
WAN throughput: Up to 1 Gbps
VPN throughput: Up to 500 Mbps
LAN switching throughput: Up to 1 Gbps
Concurrent sessions: Up to 100,000
NAT throughput: Up to 1 Gbps
Maximum VPN tunnels: 20
VLAN IDs: 4,094
MAC address table size: 4,000

Power Specifications:
Power supply: External AC adapter, 100-240V AC, 50-60 Hz input
Maximum power consumption: 60W
Power over Ethernet (PoE) support: IEEE 802.3af PoE, 15.4W per port

Environmental Specifications:
Operating temperature: 32 to 104°F (0 to 40°C)
Storage temperature: -4 to 149°F (-20 to 65°C)
Operating humidity: 10 to 85% non-condensing
Storage humidity: 5 to 95% non-condensing

Connectivity Specifications:
Interfaces: 1 x Gigabit Ethernet WAN port, 4 x Gigabit Ethernet LAN ports, 1 x USB 3.0 port, 1 x console port
LAN ports PoE support: 4 x 10/100/1000 PoE
Wireless standards: IEEE 802.11a/b/g/n/ac Wave 2
Wireless frequency bands: 2.4 GHz and 5 GHz

Software Specifications:
Routing protocols: Border Gateway Protocol (BGP), Open Shortest Path First (OSPF), Enhanced Interior Gateway Routing Protocol (EIGRP), Routing Information Protocol (RIP), Static Routing, Policy-Based Routing (PBR), Virtual Routing and Forwarding (VRF)
VPN protocols: IPsec, Point-to-Point Tunneling Protocol (PPTP), Layer 2 Tunneling Protocol (L2TP), OpenVPN
Security features: Firewall, intrusion prevention system (IPS), content filtering, URL filtering, VPN encryption, NAT, Access Control Lists (ACLs), VLANs
Quality of Service (QoS) features: Traffic shaping, classification and marking, bandwidth guarantees, priority queuing

Additional Specifications:
Integrated LTE modem support: Yes
SD-WAN support: Yes
Network management: Cisco DNA Center, Cisco IOS Software CLI, Simple Network Management Protocol (SNMP), Cisco Prime Infrastructure, Cisco Configuration Professional
IPv6 support: Yes
Cisco DNA software subscription: Required for full functionality

The Cisco C1111-4P router offers a wide range of advanced features, including built-in wireless capabilities, PoE support, and integrated LTE modem support, making it an excellent choice for small to medium-sized businesses that require reliable and secure connectivity. Its compact design and easy management also make it an ideal solution for branch offices and remote sites.

C1111-4P ISR 1100 4 Ports Dual GE WAN Ethernet Router
C1111-4PLTELA ISR 1100 4P Dual GE WAN w/ LTE Adv SMS/GPS LATAM and APAC
C1111-4PWH ISR 1100 4 Ports Dual GE WAN Router w/ 802.11ac -H WiFi
C1111-8P ISR 1100 8 Ports Dual GE WAN Ethernet Router
C1111-8PLTELA ISR 1100 8P Dual GE Router w/ LTE Adv SMS/GPS LATAM & APAC
C1111-8PLTELAWH ISR 1100 8P Dual GE WAN w/ LTE Adv SMS/GPS 802.11ac -H WiFi
C1111-8PWH ISR 1100 8 Ports Dual GE Ethernet Router w/ 802.11ac -H WiFi
