ASR1001

Manufacturer Part#: Cisco ASR1001
ASR1001 CISCO ASR 1001 Aggregation Services Router ASR1001

ASR1001 in stock and ready to ship

The Cisco ASR1001 Router offers a default system bandwidth of 2.5 Gbps upgradable to 5 Gbps with a software-activated upgrade license. It houses one shared port adapter (SPA) slot that supports single-height SPAs. It includes four built-in Gb Ethernet ports. The first IOS XE software release supporting ASR 1001 is Cisco IOS XE 3.2.0S.

The Cisco ASR1001 Router also introduces the concept of integrated daughter cards (IDCs). Six models of the Cisco ASR 1001 Router are currently available:
• ASR1001: without an IDC
• ASR1001-2XOC3POS: with an IDC that provides two OC3 POS ports
• ASR1001-4XT3: with an IDC that provides four T3 ports
•ASR1001-4X1GE : with four 1-Gigabit Ethernet ports
•ASR1001-HDD (160 GB): with a 160-GB hard disk drive
•ASR1001-8XCHT1E1 : with eight channelized T1/E1 ports

The ASR1001 is ideal for:
• High-end enterprise branches
• Managed services, including VPN and firewall
• WAN aggregation and secure WAN
• Deep packet Inspection (DPI)
• Route reflector
• Low-end broadband aggregation (LNS)

Cisco ASR1001 router is a small footprint edge routing solution that delivers high performance throughput with services turned on, enabling deployment agility in high-end enterprise branch, WAN edge, and managed services environments.

ASR1001 Memory options
• Four 2-GB DDR2 mini-DIMMs
• Four 4 GB DDR2 mini-DIMMs
• Upgradable memory from 8-GB to 16-GB DRAM

Chassis support
Cisco ASR 1004 and ASR 1006 chassis
(Note: The Cisco ASR 1002 and ASR 1002 Fixed chassis come with the Cisco ASR 1000 Series RP1 built into the chassis.)

ASR1001 Connectivity
• Console port (RJ-45 connector)
• Auxiliary port (RJ-45 connector)
• 10/100/1000 Ethernet port (RJ-45 connector)
• RJ-48 connector for BITS input clock and output source

ASR1001 Performance
With 8-GB memory:
• 1,000,000 IPv4 routes or 1,000,000 IPv6 routes
• BGP RR Scalability to 8,000,000 IPv4 routes or 6,000,000 IPv6 routes
With 16-GB memory:
• 4,000,000 IPv4 routes or 4,000,000 IPv6 routes
• BGP RR Scalability 24,000,000 IPv4 routes or 17,000,000 IPv6 routes
