AIR-LAP1041N-E-K9

Manufacturer Part#: Cisco AIR-LAP1041N-E-K9
AIR-LAP1041N-E-K9 Cisco Wireless Access Point (AP)

AIR-LAP1041N-E-K9 - Cisco AIR-LAP1041N-E-K9 Single Band Controller Based Radio Access Point

In stock & Ready to ship

AIR-LAP1041N-E-K9 Technical Details
Data transfer rate (max): 300 Mbit/s
Ethernet LAN (RJ-45) ports quantity: 1
Wireless technology: Wi-Fi
Horizontal beam width: 360 degree
LED indicators

AIR-LAP1041N-E-K9 Specification:
New Original Cisco 802.11g/n Fixed Unified AP; Int Ant; E Reg Domain
Device Type: Wireless access point
Enclosure Type: External
RAM Installed ( Max ): 128 MB
Flash Memory Installed (Max): 32 MB flash
Data Link Protocol: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Remote Management Protocol: SNMP

AIR-LAP1041N-E-K9 Software
•Cisco Unified Wireless Network Software Release 7.0 or later
•Cisco IOS Software Release 12.4(21a)JA

AIR-LAP1041N-E-K9 Data Rates Supported
•802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
•802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
•802.11n data rates 300 Mbps

AIR-LAP1041N-E-K9 802.11n Capabilities
•Maximal ratio combining (MRC)
•20- and 40-MHz channels
•PHY data rates up to 300 Mbps
•Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
•802.11 dynamic frequency selection (DFS) (Bin 5)
•Cyclic shift diversity (CSD) support

AIR-LAP1041N-E-K9 Integrated Antenna
•2.4 GHz, Gain 4.0 dBi, horizontal beamwidth 360°

Interfaces
•10/100/1000BASE-T autosensing (RJ-45)
•Management console port (RJ45)

EAP Type(s)
•Extensible Authentication Protocol-Transport Layer Security (EAP-TLS)
•EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
•Protected EAP (PEAP) v0 or EAP-MSCHAPv2
•Extensible Authentication Protocol-Flexible Authentication via Secure Tunneling (EAP-FAST)
•PEAPv1 or EAP-Generic Token Card (GTC)
•EAP-Subscriber Identity Module (SIM)

AIR-LAP1041N-E-K9 Multimedia
•Wi-Fi Multimedia (WMM)

Other
•FCC Bulletin OET-65C
•RSS-102
