15454-ML100X-8

Manufacturer Part#: Cisco 15454-ML100X-8
15454-ML100X-8 Interface & Line Card

15454-ML100X-8 - 8 x SFP - Interface Card

Cisco ML100X-8 card for the Cisco ONS 15454 MSPP is industry-leading Ethernet and IP switching modules for integration into a SONET/SDH optical transport platform. The cards extend the multiservice capabilities and flexibility offered by the Cisco ONS 15454 platform.

15454-ML100X-8 Original Manufacturer Warranty:
Standard Warranty: 90 Day Limited

Cisco 15454-ML100X-8 General Information:
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Series: ML
Product Model: ML100X-8
Product Name: ONS 15454 ML100X-8 Ethernet Interface Card
Product Type: Interface Card

Cisco 15454-ML100X-8 Interfaces/Ports:
Interfaces/Ports Details: 1 x DB-9 Serial
Interfaces/Ports Details: 1 x RJ-11 Console Management

Cisco 15454-ML100X-8 Media & Performance:
Connectivity Media: Twisted Pair
Data Transfer Rate: 100Mbps Fast Ethernet

Cisco 15454-ML100X-8 I/O Expansions:
Expansion Slots: 8 x SFP

Cisco 15454-ML100X-8 Management & Protocols:
Management:
Cisco IOS Software CLI through console port
Telnet
Configured user (client) port
Cisco transport controller window Simple Network Management Protocol (SNMP) traps
SLA management
Cisco IOS Software CLI through console port
Telnet
Configured user (client) port
Cisco transport controller window Simple Network Management Protocol (SNMP) traps
SLA management

15454-ML100X-8 Security Features: Access Control Lists (ACL)

Cisco 15454-ML100X-8 Controls/Indicators:
Status Indicators:
Card LEDs:
•Failure (FAIL)
•Status (ACT)

15454-ML100X-8 Port LEDs (per port):
•Link (LINK)
•Activity (ACT)

Cisco 15454-ML100X-8 Power Description:
Power Consumption: 53 W

Cisco 15454-ML100X-8 Environmental Conditions:
Temperature: -5 degrees C (23.0 degrees F) to 55 degrees C (131.0 degrees F) Operating
Temperature: -40 degrees C (-40.0 degrees F) to 85 degrees C (185.0 degrees F) Storage
Humidity: 5% to 95% Non-condensing Operating
Humidity: 5% to 95% Non-condensing Storage

Cisco 15454-ML100X-8 Physical Characteristics:
Dimensions: 12.65 Height x 0.72 Width x 9 Depth - Single card slot
Weight: 2.59 lb
